Installation Dimension Diagram
Installation dimension diagram
48K
30cm
Space to the ceiling
Air outlet side
Space to the wall: (30cm at
10cm
least for the pipe side)
5cm
Space to the rear side
Space to the obstruction
Air inlet side
10cm above
Space to the wall
60cm above
Space to the wall
Air outlet side
