Name and Function of Each Button of Air Conditioner
Function Button and Display of Air Conditioner
Operation Display
● When the unit is energized, the display
will be on.
Setting
Set temperature is displayed.
●
Room Temperature
● Room temperature is displayed.
Turbo
●
When "Turbo" is bright, turbo function
is set.
TIMER
Timer Display
Set timer to turn on or turn off the unit.
●
● Timer can only be set by remote control.
FAN
Fan Display
● In this mode, compressor doesn't operate
and only indoor fan operates.
AUTO
Auto Display
● In this mode, the operation mode will
be determined by controller based on
change of room temperature.
空调器功能键 空调器功能键
Function Button of Air Conditioner
Room Temperature Display/Set
Temperature Display/ Timer Display
Set temperature can be set by function
●
button or remote control.
Timer can be set by remote control.
●
●
Where there is malfunction, only
malfunction code will be displayed.
During normal operation, if temperature
●
or timer is set by button or remote
signal, the corresponding setting will
be displayed for 5 seconds and then
set temperature will be displayed (set
temperature or room temperature).
During defrosting operation, H1 will be
displayed as default. If set temperature,
timer, temperature display are set by
button or remote control, the display
will follow the following sequence: set
temperature, timer, temperature display.
During defrosting operation(H1), each
status will be displayed for 5 seconds
and then next status will be entered. If
the status (set temperature, timer,
temperature display or defrosting)
doesn't change, it will not be displayed
and the default or set temperature will
be displayed finally. The room
temperature will be displayed as default
after energization.
