Installation Service-Notes for Installation
1. The unit installation work must be done by qualified personnel according to the local rules
and this manual.
2.When removing the unit to the other place, please firstly contact with the local maintenance
center.
Installation at the following places may cause failure of the air conditioner. Please contact
installation and service agency if the installation at such places cannot be avoided.
●
Choose a place far away from heat source, steam and inflammable gases.
●
A place with high frequency facilities, such as radio equipment, electric welder or
medical equipment;
●
A region with saline-sodic soil near the sea;
●
A place full of machine oil;
●
A place with sulphide gases (such as sulphur spring);
●
An environment with special conditions.
1. Select a place, avoid the inflammable gas produce or leakage.
2. Select a place avoid the water vapor or oil sprayed on the unit.
3. Ensure that airflow can reach every conner of the room.
4. Choose a place so that the connection pipe could be easily pulled out.
5. Select the place where the airflow of the unit can not be blocked.
6. Select the position where the few outer air influenced.
7 . Select the firm and flat ground.
8. Ensure sufficient clearance and space for service and maintenanc.
9. Ensure the installation of indoor unit is in conformity with the requirements of installation
dimension drawing;
1. A place where noise and airflow generated by air exhaust do not affect the neighbors,
animals and plants.
2. Ensure good ventilation of outdoor unit.
3. No obstacles near the outdoor unit obstructing the air intake and air exhaust of the unit.
4. The installation position shall be able to withstand the weight and vibration of the outdoor unit.
5. Choose a place far away the direct sunshine or strong wind.
6.The indoor unit shall be in conformity with the requirements of installation diagram,
and ensure sufficient clearance and space for service and maintenance.
7. The height of connection pipe should be within 5meters, and the length of it should be
within 10meters.
8. Please select the place keep out of the children's reach.
9. Select the place which do not influence the communal path way and the appearance
of the city.
Important notices
Basic requirements for installation location
Installation location of indoor unit
Installation location of outdoor unit
25
