AccessZone ® - GC500 Series – GC501-GC504 User Manual

15 Default Factory System Settings

Here is a short recap of the systems default settings:
Virtual Keypad user 0xFFFFFFFFFF with PIN 1234 is default on storage position 01
Door/gate remain open time is set to 5 seconds
Alarm arm/disarming is enabled and can be used by the first 5 users
Detection range is approximately 20-40 cm
Master PIN code is 12345678 – Please change this as the first thing
Below is a list of the commands for the default factory settings. These can be restored:
System Master PIN Code
12345678
Default System Settings 1
Normal Operation Mode
05,01,1,0,05,10
Default System Settings 2
Normal Operation Mode
1,3,40,0,0,1,1
Default User
01,FFFFFFFFFFFF,1234,2

15.1 Restore Factory Default System Settings

The Master PIN code and the other system configuration settings can be restored to factory
settings:
Please follow the below steps:
Steps:
Power off the device
Disconnect input 1 and input 2 (remove connection to sensors and REX button)
Disconnect output 1 (remove connection to alarm system/light control)
Connect (short) input 1 and input 2 with output 1
Power on the device – Wait - a short beep acknowledges that the factory settings have
been restored
Power off the device again
Reconnect input 1 and input 2 (connect to sensors and REX button)
Reconnect output 1 (connect to alarm system/light control)
Device can safely be re-powered with the restored factory settings.
Caution!
General caution must be taken when working with the wires to avoid short circuits etc.
All information is subject to change without notice. All other products and brand names are registered trademarks of their respective companies
Copyright © 2005-2010 All rights reserved MVC-Data ApS Skalhuse 5 9240 Nibe Denmark Web
Note! Settings in bold is fixed for the
duration of the system configuration mode.
System Settings 2
System Configuration Mode
1,2,30,0,0,1,1
www.mvc-data.com E-mail info@mvc-data.com Phone +45 25 12 84 02
2010-07-06 US 1.17
30/34
