AccessZone ® - GC500 Series – GC501-GC504 User Manual
13 Door/Gate Output Type
The GC500 series support 3 different door/gate output types: Pulse, Level or Latched (toggle) to
support different door/gate mechanisms. All types can be combined with a warning buzzer period
before gate activation (warning buzzer can also be switched off).
Select the type suitable for your door or gate.
13.1 Pulse
A 1 second pulse is used to activate the gate and another 1 second pulse is used to close the gate
again after the time out of the "remain gate open time" period.
Door/Gate Output 2
Warning open time with buzzer
13.2 Level
A pulse is used to activate the gate. The length of the pulse depends on the "remain open time"
period.
Door/Gate Output 2
Warning open time with buzzer
13.3 Latched (toggle)
The output is kept from one valid access to the next where it changes (toggle).
Door/Gate Output 2
Warning open time with buzzer
All information is subject to change without notice. All other products and brand names are registered trademarks of their respective companies
Copyright © 2005-2010 All rights reserved MVC-Data ApS Skalhuse 5 9240 Nibe Denmark Web
-------- Remain open time-------
_____|
|______________________|
Warning close time with buzzer
--------- Remain open time--------
_____|
Warning close time with buzzer
_____|
......
Warning close time with buzzer
|___
|___
|___
www.mvc-data.com
E-mail
info@mvc-data.com
2010-07-06 US 1.17
27/34
