9 Default Factory System Settings

9.1 GC630/GC640 Series
The system configuration settings can be restored to factory settings:
Please follow the below steps:
Power off the device
Short the 4 RS422 signals:
o TxA to RxA
o TxB to RxB
Power on the device – Wait - a short beep acknowledges that the factory settings have
been restored
Power off the device again
Reconnect the 4 RS422 signals
Device can safely be re-powered with the restored factory settings.
Caution!
General caution must be taken when working with the wires to avoid short circuits etc.
9.2 GC3000 Series
Please follow the below steps:
Power off the device
Open the box
Short the PIN 2-7 in J79 (it has no run-time functionality)
Power on the device – Wait - a short beep acknowledges that the factory settings have
been restored
Power off the device again
Remove the short the PIN 2-7 in J79 again
Device can safely be re-powered with the restored factory settings
TIP!
Add a jumper on J25 to avoid tamper alarm - remember to remove the jumper again.
