Page 1: User Manual
2 WIRE SYSTEM CDV97 Series Fisheye door station with proximity access control USER MANUAL RF CARD RF CARD RF CARD RF CARD CDV97-1ID CDV97-2ID CDV97-4ID CDV17-97A Please read carefully to ensure safe and correct operation Keep this manual safe for future use... -
Page 2: Table Of Contents
CONTENTS PARTS AND FUNCTIONS ..................3 Part Names......................3 Mounting ......................... 4 BASIC FUNCTIONS ....................6 Unlock Operations ....................6 Fisheye Camera ..................... 6 External Motion Detection ..................6 SETUP INSTRUCTIONS ..................7 Functions Setting Up ....................7 Setting Door Station Address ................. 8 Setting Door Station Calling Mode ................. -
Page 3: Parts And Functions
PARTS AND FUNCTIONS Part Names Surface mounted [10] [11] [12] [13] Flush mounted [14] [11] [12] [13] [1] Microphone [5] Nameplate [10] Rain Shield [2] UNLOCK indicator [6] Front panel [11] Mounting hook [3] CALL indicator [7] Speaker [12] Connection port [4] Call button [8] Night view LED [13] Screw hole... -
Page 4: Mounting
PARTS AND FUNCTIONS Mounting The installation height is suggested at 145~160cm. Surface mounted The distance between the top of main unit Rainy cover ≥3mm and rain cover should be not less than 3mm. Main unit Rainy cover Main unit AcDbMLeader (ACDB_MLEADER_CLASS) AcDbMLeader (ACDB_MLEADER_CLASS) 1. - Page 5 PARTS AND FUNCTIONS Terminal description Lock Control Jumper PIR Motion Detector Connect Port P L S + L 1 L 2 Main Connect Port Lock Control Jumper: To select the lock type. Motion Detector Connect Port: To connect external PIR motion detector. Main Connect Port: To connect the bus line and the electronic locks.
-
Page 6: Basic Functions
BASIC FUNCTIONS Unlock Operations Unlocking by ID Card/Tag When the registered user card is shown to the ID card window, the UNLOCK indicator lights up, the buzzer sounds,and the electric door strike is unlocked. • Present an authorised user card, the buzzer will beep once, the UNLOCK indicator will light up and the connected lock will release. -
Page 7: Setup Instructions
SETUP INSTRUCTIONS Functions Setting Up This section explains the settings of each function. Please refer to the following table: To perform the settings for the function LED_UNLOCK required, remove the metal front panel to LED_TALK gain access to the 'Key Set' button. KEY_SET Please refer to the diagram (right). -
Page 8: Setting Door Station Address
SETUP INSTRUCTIONS Setting Door Station Address A total of 4 addresses can be configured. They can be modified either before or after installation. 0 is default, to change the setting, please use the following steps: ID=0, 1 door station ID=1, 2 door station ID=2, 3 door station... - Page 9 SETUP INSTRUCTIONS Each call button will respond different addresses when set in different calling mode. Refer to the following for more information. 1. Standard calling mode(Address range 01-04 by default) Call button A: calls monitor address 01 by default. Call button B: calls monitor address 02 by default. Call button C: calls monitor address 03 by default.
-
Page 10: Setting Camera Resolution
SETUP INSTRUCTIONS Setting Camera Resolution The resolution of the camera can be changed between high and low quality at the door station. High resolution is default, to change the setting, please follow the steps: In standby mode, press Press KEY_2 button to set the Press KEY_2 button again KEY_SET button twice. -
Page 11: Setting Unlock Time
SETUP INSTRUCTIONS Setting Unlock Time By default, the unlock time is 1s, this can be changed between 1s~99s. Follow the steps below: Press and hold on KEY_2 In standby mode, press KEY_SET button three button. The time held on is times. -
Page 12: Setting Night View Led Illumination Mode
SETUP INSTRUCTIONS Setting Night View LED Illumination Mode There are 3 working modes for night view LED indicator, Normally on, Normally off and Auto. Auto is default, to change the setting, please use the following steps: In standby mode, press Press KEY_4 button to set Press KEY_4 button again Press KEY_4 button again... -
Page 13: Setting Image Display Mode
SETUP INSTRUCTIONS Setting Image Display Mode Please note this setting is only for monitors that do not support manual pan, tilt and zoom functions, i.e. CDV47M, CDV43 & CDV24. When calling a monitor: When a call is placed from door station to a monitor, the image is displayed on screen. There are 3 modes for the image that can be displayed;... -
Page 14: Registering Id Card
SETUP INSTRUCTIONS Full screen mode: When answering the call, the image will be displayed on Zoom mode for 5 seconds, then switch to Full screen as a reminder to enter the talk status. If deactivated, no image switching reminder is displayed on any image display mode. Activated is default, to change the setting, please use the following steps: Press KEY_3 button to Press KEY_3 button again to... - Page 15 SETUP INSTRUCTIONS Power on, within 10s,press Press KEY_2 button. Show the first card to ID Show the second card to ID and hold KEY_SET button card window, set the card card window, set the card of for 3s. of MASTER CARD ADD. MASTER CARD DELETE.
- Page 16 SETUP INSTRUCTIONS Adding User Cards: Show the master card of Show user cards to be Show the master card of MASTER CARD ADD to ID added in sequence. MASTER CARD ADD again card window in standby. to exit. UNLOCK Indicator:OFF UNLOCK Indicator:OFF UNLOCK Indicator:OFF TALK Indicator:ON...
-
Page 17: Wiring
WIRING Connecting Electric Lock Door Lock Controlled with Internal Power 1 2 3 1.Electronic lock of Power-on-to-unlock (fail Secure) type should be used. Jumper position on 2&3 2.The door lock is limited to 12V, and hold- ing current must be less than 250mA. PL S+ S- 3.The jumper should be placed on position 2 and 3 before connecting. -
Page 18: Connecting Basic One-To-One
WIRING Connecting Basic One-to-one ID=0 Code=1, DIP6=on 100~240VAC PC6A RF CARD BUS(IM) BUS(DS) L1 L2 PL S+ S- DIP Switches 1 2 3 4 5 6 • The door station work in Standard mode in this example. Refer to Page 9 in detail. •... -
Page 19: Connecting Multi Monitors
WIRING Connecting Multi Monitors Basic IN-OUT Wiring in Standard Mode • The door station is also compatible with other monitors within the 2Easy range. Code=1, DIP6=on (Slave 3) • Please set door station into group calling mode if there is more than 4 monitors in villa (house or apartment). - Page 20 WIRING Star Topology Wiring With DBC4A1 in Standard Mode Code=1，DIP6=on Code=2，DIP6=on Impedance OFF ON switch Code=3，DIP6=on Code=4，DIP6=on 100~240VAC PC6A DBC4A1 BUS(IM) BUS(DS) Optional functional modules: BDU bus amplifier module RLC staircase light controller module DBC4A1 2/4 inputs branch distributor RF CARD ID=0 •...
-
Page 21: Appendix
APPENDIX Precautions • Please clean the unit with soft cotton cloth, do not use chemical clean agents. If necessary, use a little pure water or dilute soap & water to clean off the dust and dirt. • The unit is weather resistant. However do not spray high pressure water on access control keypad directly, excessive moisture will damage the unit. -
Page 22: Cables And Requirements
APPENDIX Cables and Requirments The maximum distance of the wiring is limited within the 2Easy system. Using different cables may also affect the maximum distance which the system can reach. Basic IN-OUT Wiring Mode Cable and distance(unit:m) Cable Usage ≤2 IM ≤16 IM Belden 9470 UTP 2x0.75mm Belden 8471 UTP 2x1mm... - Page 23 APPENDIX Star Topology Wiring Mode With DBC4A1 DBC4A1 PC6A Cable and distance(unit:m) Cable Usage Belden 9740 UTP 2x0.75mm Belden 8471 UTP 2x1mm RF CARD -23-...
- Page 24 CDV-ENG-97-V1 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
