- Page 1 YEAR WARRANTY CDV-91IP 2EASY IP, 1-Button Video Door Station...
-
Page 2: Table Of Contents
CDV-91IP 2EASY IP, 1-Button Video Door Station 1] CONTENTS Title Page 2] Parts and Functions 3] Installation 4] System Wiring and Connections 5] Electric Lock Connections 6] Door Station Operations 7] Specifications 8] Precautions... -
Page 3: Parts And Functions
CDV-91IP 2EASY IP, 1-Button Video Door Station 2] PARTS AND FUNCTIONS Camera Lens Speaker Microphone LED_LOCK Call button LAN connector Indicates unlock status. Press to call the indoor Use to connect the door monitor (resident). station to the network. LED_CAM... -
Page 4: System Wiring And Connections
CDV-91IP 2EASY IP, 1-Button Video Door Station 1. Recommended installation height for door stations is 145-160cm. 2. Use screws to fix the back panel to the wall after connecting the cable. 3. Attach the front panel to the back panel, then use a screw to fix it. -
Page 5: Electric Lock Connections
CDV-91IP 2EASY IP, 1-Button Video Door Station 5] ELECTRIC LOCK CONNECTIONS Door lock controlled with internal power Notes: 1. This mode only supports strike LK - type locks. 2. Fail safe electromagnetic locks N.O. (power off to unlock) should be... -
Page 6: Door Station Operations
CDV-91IP 2EASY IP, 1-Button Video Door Station 6] DOOR STATION OPERATIONS Call button linked in Villa mode Connect all the devices and power them on. On the indoor monitor (CDV-471IP): 1. From the main menu, tap the Setting icon. 2. Select Ext.Unit, and then tap Auto Setup Wizard. -
Page 7: Specifications
