Page 1: User Manual
CDV-ENG-97-8ID-V1 / 201708 2 WIRE SYSTEM CDV97-8ID Series 8 Button Door Station With Proximity Access Control & Fish Eye Camera USER MANUAL RF CARD CDV97-8ID • Please read this manual thoroughly to ensure safe and correct operation. • Please keep this manual safe for future use. -
Page 2: Table Of Contents
CONTENTS PARTS AND FUNCTIONS ..................3 Part Names......................3 Mounting ......................... 3 Terminal Description ....................4 BASIC FUNCTIONS ....................5 Unlock Operations ....................5 Fisheye Camera ..................... 5 SETUP INSTRUCTIONS ..................6 Functions Setting Up ....................6 Setting Door Station Address ................. 7 Setting Camera N/P Standard ................ -
Page 3: Parts And Functions
PARTS AND FUNCTIONS Part Names [10] [11] [12] [1] Microphone [4] Call button [7] Night view LED [10] Mounting holes [11] Connection port [2] UNLOCK indicator [5] Nameplate [8] Camera lens [3] CALL indicator [6] Speaker [9] Rain cover [12] External key module Mounting The installation height is suggested to 145~160cm. -
Page 4: Terminal Description
PARTS AND FUNCTIONS 3. Install the name plate. 4. Attach the front panel to the rain cover. 5. Use the special screwdriver and the screws to fix the panel. Terminal Description Lock Control Jumper 3P Connect Port P L S + L 1 L 2 Main Connect Port Lock Control Jumper:... -
Page 5: Basic Functions
BASIC FUNCTIONS Unlock Operations Unlocking of ID Card When the registered user card has been shown to ID card window, the UNLOCK indicator lights up, the buzzer sounds,and the electric door strike is unlocked. • If show the authorized user card,the buzzer will sound of beep+,and the UNLOCK indicator will light up. -
Page 6: Setup Instructions
SETUP INSTRUCTIONS Functions Setting Up This section explains the settings of each function, please refer to the following table: To perform the settings for the function LED_UNLOCK you want,you should move away the metal LED_CALL front panel. Please refer to the sketch KEY_SET KEY_4 map. -
Page 7: Setting Door Station Address
SETUP INSTRUCTIONS Setting Door Station Address A total of 4 addresses can be configured. The address can be modified either before or after installation. 0 (DS #1) is default, to change the address, please use the following steps: ID=0,1 door station ID=1,2 door station ID=2,3... -
Page 8: Setting Camera N/P Standard
SETUP INSTRUCTIONS Setting The Camera NTSC/PAL Video Standard The video standard of the camera can be changed at any time, that means the quality of image on screen can be set to differ. P (PAL) standard is default, to change the setting, please follow the steps: In standby mode, press Press KEY_2 button to set the Press KEY_2 button again... -
Page 9: Setting Prompt Voice Volume
SETUP INSTRUCTIONS Setting Prompt Voice Volume A total of 9 volume levels can be configured. The levels can be modified either before or after installation. 6 is default; to change the setting please use the following steps: Press KEY_4 button to set the Press KEY_4 button again In standby mode, press KEY_SET button twice. -
Page 10: Setting Unlock Time
SETUP INSTRUCTIONS Setting Unlock Time By default the unlock time is 1s, this can be changed from 1s~99s. To change the unlock time please use the following steps: In standby mode, press Press and hold on KEY_2 KEY_SET button three button. -
Page 11: Setting Night View Led Illumination Mode
SETUP INSTRUCTIONS Setting Night View LED Illumination Mode There are 3 working modes for night view LED indicator, Normally on,Normally off and Auto. Auto is default, to change the setting, please follow the steps: Press KEY_4 button to set Press KEY_4 button again Press KEY_4 button again In standby mode, press KEY_SET button three... -
Page 12: Setting Image Display Mode
SETUP INSTRUCTIONS Setting Image Display Mode Please note this setting is only for monitors that do not support manual pan, tilt and zoom functions, i.e. CDV47M, CDV43 & CDV24. When calling a monitor: When a call is placed from door station to a monitor, the image is displayed on screen. There are 3 modes for the image that can be displayed;... -
Page 13: Registering Id Card
SETUP INSTRUCTIONS Full screen mode: When answering the call, the image will be displayed on Zoom mode for 5 seconds, then switch to Full screen as a reminder to enter the talk status. If deactivated, no image switching reminder is displayed on any image display mode. Activated is default, to change the setting, please use the following steps: In standby mode, press Press KEY_3 button to... - Page 14 SETUP INSTRUCTIONS When power on in 10s,press Press KEY_2 button. Show the first card to ID Show the second card to ID and hold on KEY_SET button card window, set the card card window, set the card of for 3s. of MASTER CARD ADD.
-
Page 15: Restore To Default
SETUP INSTRUCTIONS Deleting User Cards: Show the master card of Show user cards to be Show the master card of MASTER CARD DELETE to deleted in sequence. MASTER CARD DELETE ID card window in standby. again to exit. UNLOCK Indicator:ON UNLOCK Indicator:Blink one time UNLOCK Indicator:OFF CALL Indicator:OFF... -
Page 16: Wiring
WIRING Connecting Electric Lock Door Lock Controlled with Internal Power 1 2 3 1.Electronic lock of Power-on-to-unlock (fail Secure) type should be used. Jumper position on 2&3 2.The door lock is limited to 12V, and hold- PL S+ S- ing current must be less than 250mA. 3.The jumper should be placed on position 2 and 3 before connecting. -
Page 17: Appendix
APPENDIX Precautions • Please clean the unit with soft cotton cloth, don't use the organic impregnant or chemical clean agent. If necessary, please use a little pure water or dilute soap water to clean the dust. • The unit is weather resistant. However do not spray high pressure water on access control keypad directly. -
Page 18: Cables And Requirments
APPENDIX Cables and Requirments The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach. Basic IN-OUT Wiring Mode Cable and distance(unit:m) Cable Usage ≤2 IM ≤16 IM Belden 9470 UTP 2x0.75mm Belden 8471 UTP 2x1mm... - Page 19 APPENDIX Star Topology Wiring Mode With DBC4A1 DBC4A1 PC6A Cable and distance(unit:m) Cable Usage Belden 9740 UTP 2x0.75mm Belden 8471 UTP 2x1mm RF CARD -19-...
- Page 20 CDV-ENG-97-8ID-V1 / 201708 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
