B.1 Introduction
B.2 Modbus Register Map Sections
EPM 2200 POWER METER – INSTRUCTION MANUAL
EPM 2200 Power Meter
Appendix B: Modbus Mapping for
Modbus Mapping for EPM 2200
The Modbus Map for the EPM 2200 Meter gives details and information about the possible
readings of the meter and about the programming of the meter.
The EPM 2200 can be programmed using the buttons on the face plate of the meter (6.1
Programming Using the Faceplate). The meter can also be programmed using software. For
a Programming Overview, see section 6.4 GE Communicator Programming Overview of this
manual. For further details see the GE Communicator Instruction Manual.
The EPM 2200 Modbus Register Map includes the following sections:
Fixed Data Section, Registers 1- 47, details the Meter's Fixed Information.
Meter Data Section, Registers 1000 - 5003, details the Meter's Readings, including Primary
Readings, Energy Block, Demand Block, Maximum and Minimum Blocks, THD Block, Phase
Angle Block and Status Block. Operating Mode readings are described in Section 6.1.13
Operating Mode on page 6–14.
Commands Section, Registers 20000 - 26011, details the Meter's Resets Block,
Programming Block, Other Commands Block and Encryption Block.
Programmable Settings Section, Registers 30000 - 30067, details the Meter's Basic Setups.
Secondary Readings Section, Registers 40001 - 40100, details the Meter's Secondary
Readings Setups.
EPM 2200
B–1
