16 Working with measurement tools
16.5.4.2 Changing local parameters
You can change the local parameters for a measurement tool.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the joystick. This displays a context menu.
3. Use the joystick to go to
4. Push the joystick.
5. Push the joystick to activate the use of local parameters.
cator) is displayed together with a submenu.
6. Select an object parameter.
7. Push the joystick to display a dialog box.
8. Use the joystick to change the parameter.
9. Push the joystick. This closes the dialog box.
10. When completed, push the joystick and select

16.5.5 Related topics

For in-depth information about parameters, and how to correctly set the emissivity and
reflected apparent temperature, see 32 Thermographic measurement techniques, page
78.

16.6 Displaying values in the result table and displaying a graph

16.6.1 General

For the box, circle, and line tools, you can set the camera to display the maximum, mini-
mum, and average values in the result table.
For the line tool, you can also display a graph.

16.6.2 Procedure

Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the joystick. This displays a context menu.
3. Use the joystick to go to (depending on the tool)
Alarm) or (Graph/Max/Min/Avg/Alarm).
4. Push the joystick. This displays a submenu.
• Select (Graph) and push the joystick to display a graph.
• Select (Max) and push the joystick to display the maximum value.
• Select (Min) and push the joystick to display the minimum value.
• Select (Avg) and push the joystick to display the average value.
5. When completed, move the joystick down to close the submenu.
6. Select (Done) and push the joystick.
#T559879; r. AG/12171/13006; en-US
(Use local parameters).
(icon with grey indicator) is displayed.
(Done).
,
(icon with blue indi-
, or (Max/Min/Avg/
