Intelligent True On-Line UPS
For Corporate and IT Users
User Manual
1, 2, and 3 kVA
Table of Contents
1.
Safety and Storage Instructions .............................................................2
1.1 Safety ........................................................................................................2
1.2 Storage .....................................................................................................3
2.
Product Introduction ...............................................................................4
2.1 General Characteristics ............................................................................4
2.2 Special Features .......................................................................................5
3.
UPS Functional Descriptions..................................................................6
3.1 Front Panel Display ..................................................................................6
3.2 Rear Panel ..............................................................................................11
3.3 Communication Port Explanation ...........................................................12
4.
Installation and Operation.....................................................................13
4.1 Unpacking ...............................................................................................13
4.2 Selecting Installation Position .................................................................16
4.3 Operation ................................................................................................17
5.
UPS System Block Diagram.................................................................30
6.
Maintenance Guide ..............................................................................31
6.1 Troubleshooting ......................................................................................31
6.2 Error Codes and Their Meanings ...........................................................34
6.3 Maintenance ...........................................................................................34
7.
Communication Software .....................................................................35
7.1 Hardware Setup ......................................................................................35
7.2 Software Installation ...............................................................................35
8.
Optional Communication Cards ...........................................................36
8.1 R2E (second RS-232) card.....................................................................36
8.2 USE (USB) card......................................................................................36
8.3 DCE (Dry Contact) card ..........................................................................37
8.4 SNMP Cards ...........................................................................................38
9.
Specifications Convertible Type (Rack / Tower) ..................................39
1
Advertisement
Table of Contents
Related Manuals for Ablerex ARES RT-1K
Summary of Contents for Ablerex ARES RT-1K
-
Page 1: Table Of Contents
Table of Contents Safety and Storage Instructions .............2 1.1 Safety ......................2 1.2 Storage .....................3 Product Introduction ................4 2.1 General Characteristics ................4 2.2 Special Features ..................5 UPS Functional Descriptions..............6 3.1 Front Panel Display ..................6 3.2 Rear Panel ....................11 3.3 Communication Port Explanation ............12 Installation and Operation..............13 4.1 Unpacking ....................13 4.2 Selecting Installation Position ..............16... -
Page 2: Safety And Storage Instructions
13. Ensure that the input voltage of the UPS matches the utility supply voltage. Use a certified input power cable with the correct plugs and sockets for the 1. Safety and Storage Instructions system voltage. 1.1 Safety 1.2 Storage Do not open the case as there are no serviceable parts inside. Opening the case will void your warranty and introduces the risk of electric shock. -
Page 3: Product Introduction
2.2 Special Features 2. Product Introduction Our High Frequency Transformer-less technology and tower-convertible 2.1 General Characteristics enclosure enables the UPS to be integrated into even the most difficult environments with space constraints. 1. True on-line technology continuously supplies your critical device with stable, regulated, transient-free, pure-sine-wave AC power. -
Page 4: Ups Functional Descriptions
3. UPS Functional Descriptions LED Indicator Symbol Description 1. Solid indicates normal utility voltage. Blinking 3.1 Front Panel Display indicates insufficient utility voltage for the full load. Off indicates abnormal utility voltage. Normal Mode LED 3.1.1 ARES RT< Convertible Type (Rack / Tower)> LED Panel (Standard) 2. - Page 5 3.1.2 ARES RT< Convertible Type (Rack / Tower)> LCD panel Special functions log in/out 6 Button LCD Panel Go to next page Go to previous page or change the setting of the UPS. To re-confirm the change of UPS Setting Manual Bypass Press "...
-
Page 6: Rear Panel
3.2 Rear Panel 3.1.3 LCD displayer description ARES RT 230V Item Sign Description Bypass Input Abnormal, UPS fails to transfer to bypass, Bypass Abnormal at ECO mode Utility Input Abnormal Site Wiring Fault Buzzer Silent UPS Overloading UPS Working in specified mode* Emergency Power Off (EPO) dry contact signal inputs USB port* RS-232 port... -
Page 7: Communication Port Explanation
4. Installation and Operation 3.3 Communication Port Explanation Please read the Safety Instruction guide (pages 2 and 3) before installing the UPS. The UPS is equipped witha true RS-232 communication port as standard to provide communication with bundled UPS monitoring software for remote 4.1 Unpacking monitoring of the UPS status using a PC. - Page 8 Step 3 4.1.1 Installation Instructions Tower installation Rack Mount installation Step 1 Step 2...
-
Page 9: Selecting Installation Position
4.3 Operation 4.2 Selecting Installation Position 4.3.1 Using the standard LED panel The UPS is heavy. Select a location sturdy enough to support the UPS weight. 4.3.1.1 Start Up in Normal AC Mode To ensure proper operation and long operating life, position the UPS according to the following requirements. - Page 10 4.3.2 LCD Panel 4.3.2.1 Line mode start up 4.3.1.3 Shutdown 1. Please ensure the outlet of power source is proper grounded. 1. Shutdown in AC Mode 2. Ensure the voltage rating of power source is matched with UPS spec. Press and hold the OFF button ‘ ’...
- Page 11 6. Back up test – Unplug inlet power cord or switch off power source to 4.3.2.3 Operation of measurements display simulate power failure condition. Green LED indicator will be dimmed and Amber LED " "," will be light. Intermittent audible 1.
- Page 12 4.3.2.4 UPS Locked up UPS may lock itself up while there was critical abnormal or failure condition happened. User may see LCD display as below figure-N. The procedures to release UPS from locked up status are as below: (a) Check and record the error code. (b) Check user’s manual to understand possible cause, solve the problem or call service provider.
- Page 13 4.3.2.5 UPS Default Data and Special Function Execution After the UPS completely starts up, press the key to change the LCD display to figure Q1. Bypass Voltage is adjusted to wide range. buzzer “On” Bypass Voltage is adjusted to narrow range. buzzer “Off”...
- Page 14 4.3.3 UPS Default Settings and their alternatives 4.3.3.1 Make sure the UPS is not “On”. Press the On and scroll down keys simultaneously for approximately three seconds. The buzzer The UPS is operating in “Eco mode”. will sound twice, and the LCD will display figure Q1, indicating that the UPS is in setting mode.
- Page 15 4.3.4 Beep Codes The following table contains common UPS statuses with their beep codes. UPS Status Beep Code UPS faulty, Inverter shut down. Long Continuous Beep All functions inhibited. Control keypad error Long Continuous Beep UPS faulty, loads continue to * Press the Enter key to save changes.
-
Page 16: Ups System Block Diagram
6. Maintenance Guide UPS System Block Diagram 6.1 Troubleshooting If the UPS malfunctions during operation please check that all lines are connected properly and that the utility specifications are correct. Then check the table below for solutions. Should the problem persist please contact your local dealer for assistance. - Page 17 UPS fails to provide If the backup time remains Error Codes battery backup or its unsatisfactory after 8 hours of When the Fault LED is lit press the ON button ‘ ’ briefly to check the backup time is shorter charging please contact your error code.
-
Page 18: Error Codes And Their Meanings
Checking error cord on LCD panel ： 7. Communication Software ， I f U P S i s i n a b n o r m a l c o n d i t i o n c o m m o n a l a r m s i g n w i l l l i g h t u p a n d 7.1 Hardware Setup c o m e w i t h a u d i b l e a l a r m . -
Page 19: Optional Communication Cards
8.3 DCE (Dry Contact) card 8. Optional Communication Cards 8.1 R2E (second RS-232) card 8.3.1 Pin assignments of 10-Pin terminal: 8.1.1 CN1 is for RS-232 DB9. 8.1.2 For interface settings and pin assignments please refer to section 3.3.1. 8.1.3 Installation Position: Optional Slot 1 Æ... -
Page 20: Snmp Cards
9. Specifications Convertible Type (Rack / Tower) 8.4 SNMP Cards MODEL ITEM ARES RT-1K ARES RT-2K ARES RT-3K 1000 VA 2000 VA 3000 VA 8.4.1 Megatec SNMP card CAPACITY when input voltage is 180~300Vac PF=0.9 (900/ 1800/ 2700W) 110/150/180~300 VAC... - Page 21 Markings 40.95Vdc ±1 ％ 81.9Vdc±1 ％ 81.9Vdc ± ％ Charging Voltage Bluk Mode Charging * The UPS Communication software may be downloaded form Ablerex Web-site at: 42.3Vdc±1 ％ 84.6Vdc±1 ％ 84.6Vdc±1 ％ Voltage http://www.ablerex.com.tw/tw/htm/support-sl.htm DC leakage current ≤ 30 µA with no AC applied and the unit in the off position...
- Page 22 192321172024002...
