Planet ADSL 2/2+ VoIP Router IAD-200W User Manual

Adsl 2/2+ voip router
Hide thumbs Also See for ADSL 2/2+ VoIP Router IAD-200W:
Table of Contents

Advertisement

Quick Links

Download this manual
ADSL 2/2+ VoIP Router
IAD-200, IAD-200W
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSL 2/2+ VoIP Router IAD-200W and is the answer not in the manual?

Questions and answers

Related Manuals for Planet ADSL 2/2+ VoIP Router IAD-200W

Summary of Contents for Planet ADSL 2/2+ VoIP Router IAD-200W

  • Page 1 ADSL 2/2+ VoIP Router IAD-200, IAD-200W User's Manual...

  • Page 2: Fcc Compliance Statement

    PLANET Technology. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, mer- chantability, or fitness for a particular purpose.

  • Page 3: Ce Mark Warning

    Operation is subject to the Following two conditions: (1) This device may not cause harmful interference, and (2) This Device must accept any interference received, including interference that may cause undesired operation. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncon- trolled environment.
  • Page 4 Trademarks The PLANET logo is a trademark of PLANET Technology. This documenta- tion may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.

  • Page 5: Table Of Contents

    CHAPTER 1 INTRODUCTION... 1 IAD-200 / IAD-200W Features ... 1 Package Contents ... 4 Physical Details... 5 CHAPTER 2 INSTALLATION ... 8 Requirements... 8 Procedure ... 8 CHAPTER 3 SETUP ... 10 Overview ... 10 Configuration Program ... 11 Setup Wizard ... 12 Home Screen...
  • Page 6 Routing ... 85 Upgrade Firmware... 89 CHAPTER 7 OPERATION AND STATUS ... 90 Operation ... 90 Status Screen ... 90 Connection Status - PPPoE & PPPoA... 94 Connection Details - Dynamic IP Address... 95 Connection Details - Fixed IP Address ... 97 Using VoIP ...

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction This Chapter provides an overview of the ADSL 2/2+ VoIP router (IAD-200) / 802.11g ADSL 2/2+ VoIP router's (IAD-200W) features and capabilities. Congratulations on the purchase of your new ADSL 2/2+ VoIP router – IAD-200 / 802.11g ADSL 2/2+ VoIP router –...

  • Page 8: Advanced Internet Functions

    • Auto-detection of Internet Connection Method. IAD-200W can test your ADSL and Internet connection to determine the connection method used by your ISP. • Fixed or Dynamic IP Address. IAD-200W supports both Dynamic IP Address (IP Address is allocated on connection) and Fixed IP Address.

  • Page 9: Lan Features

    • WEP support. Support for WEP (Wired Equivalent Privacy) is included. Key sizes of 64 Bit and 128 Bit are supported. WEP encrypts any data before transmission, providing protection against snoopers. • WPA-PSK support. providing protection against snoopers. The WPA-PSK is a later standard than WEP, and provides both easier configuration and greater security than WEP.

  • Page 10: Package Contents

    Package Contents The following items should be included. If any of these items are damaged or missing, please contact your dealer immediately. • The IAD-200 / IAD-200W Unit • 1 Cat-5 Ethernet (LAN) cable • 1 RJ-11 (ADSL) cable • Power Adapter •...

  • Page 11: Physical Details

    Physical Details Front-mounted LEDs IAD-200 IAD-200W Power LED On - Power on. (Green) Off - No power. Status LED Off - Normal operation. (Yellow) Blinking - This LED blinks during start up, and during a Firmware Up- grade. • 100BT - This will be ON if the LAN connection is using 100BaseT, and Blinking if data is being transferred via the LAN port.
  • Page 12 Internet On - Internet connection is available. Off - No Internet connection available. Flashing - Data is being transmitted or received.

  • Page 13: Rear Panel

    Rear Panel IAD-200 IAD-200W Connect this port to your ADSL line. ADSL port PSTN Connect this to your PSTN line (normal analog phone line). Phone Connect a standard phone here. Connect this port to your hub, using the supplied LAN cable. This button will reset the IAD-200 / IAD-200W to the factory default Reset Button (Reset to Defaults)

  • Page 14: Chapter 2 Installation

    Chapter 2 Installation This Chapter covers the physical installation of the ADSL 2/2+ VoIP router (IAD-200) / 802.11g ADSL 2/2+ VoIP router (IAD-200W). Requirements • TCP/IP protocol must be installed on all PCs. • To use the Wireless Access Point, all Wireless devices must be compliant with the IEEE 802.11g or IEEE 802.11b specifications.
  • Page 15 2. Connect LAN Cable Use the supplied LAN cable to connect the LAN port on the IAD-200 / IAD-200W to your hub. 3. Connect ADSL Cable Connect the supplied ADSL cable from the ADSL port on the IAD-200 / IAD-200W to the ADSL terminator provided by your phone company.

  • Page 16: Chapter 3 Setup

    Chapter 3 Setup This Chapter provides Setup details of the IAD-200 / IAD-200W. Overview This chapter describes the setup procedure for: • Internet Access • LAN configuration • Wireless setup • Assigning a Password to protect the configuration data. PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Con- figuration.

  • Page 17: Configuration Program

    Configuration Program The IAD-200 / IAD-200W contains an HTTP server. This enables you to connect to it, and configure it, using your Web Browser. Your Browser must support JavaScript. The configuration program has been tested on the following browsers: • Netscape 7.1 or later.

  • Page 18: Setup Wizard

    If you cannot connect If the IAD-200 / IAD-200W does not respond, check the following: • The IAD-200 / IAD-200W is properly installed, LAN connection is OK, and it is powered ON. You can test the connection by using the "Ping" command: •...

  • Page 19: Common Connection Types

    Common Connection Types Type Details Dynamic Your IP Address is allocated IP Address automatically, when you connect to you ISP. Static (Fixed) Your ISP allocates a permanent IP Address IP Address to you. Usually, the connection is "Al- ways on". PPPoE, PPPoA You connect to the ISP only when required.

  • Page 20: Home Screen

    Home Screen After finishing the Setup Wizard, you will see the Home screen. When you connect in future, you will see this screen when you connect. An example screen is shown below. Main Menu The main menu, on the left, contains links to the most-commonly used screen. To see the links to the other available screens, click "Advanced"...

  • Page 21: Lan Screen

    LAN Screen Use the LAN link on the main menu to reach the LAN screen. An example screen is shown below. Data - LAN Screen TCP/IP IP Address IP address for the IAD-200 / IAD-200W, as seen from the local LAN. Use the default value unless the address is already in use or your LAN is using a different IP address range.
  • Page 22 • The DHCP Server provides the Gateway and DNS addresses to the client, as well as allocating an IP Address. • The IAD-200 / IAD-200W can act as a DHCP server. • Windows 95/98/ME and other non-Server versions of Windows will act as a DHCP client. This is the default Windows setting for the TCP/IP network protocol.

  • Page 23: Wireless Screen (Iad-200W Only)

    Wireless Screen (IAD-200W only) The IAD-200W's settings must match the other Wireless stations. Note that the IAD-200W will automatically accept both 802.11b and 802.11g connections, and no configuration is required for this feature. To change the IAD-200W's default settings for the Wireless Access Point feature, use the Wireless link on the main menu to reach the Wireless screen.
  • Page 24 SSID This is also called the "Network Name". Enter the desired value. The default value is Wireless. • If using an ESS (Extended Service Set, with multiple access points) this ID is called an ESSID (Extended Service Set Identi- fier). •...
  • Page 25 Allow access Use this feature to determine which Wireless stations can use the Access Point. The options are: by … • All Wireless Stations - All wireless stations can use the access point, provided they have the correct SSID and security settings. •...

  • Page 26: Wireless Security (Iad-200W Only)

    Wireless Security (IAD-200W only) This screen is accessed by clicking the "Configure" button on the Wireless screen. There are 3 options for Wireless security: • Disabled - no data encryption is used. • WEP - data is encrypted using the WEP standard. •...

  • Page 27: Wpa-Psk Wireless Security

    Key Value Enter the key value or values you wish to use. The Default Key is required, the other keys are optional. Other stations must have the same key. If desired, you can generate a key from a phrase, instead of entering Passphrase the key value directly.

  • Page 28: Trusted Wireless Stations (Iad-200W Only)

    Trusted Wireless Stations (IAD-200W only) This feature can be used to prevent unknown Wireless stations from using the Access Point. This list has no effect unless the setting Allow access by trusted stations only is enabled. To change the list of trusted wireless stations, use the Modify List button on the Access Control screen.
  • Page 29 Edit Use this to change an existing entry in the "Trusted Stations" list: 1. Select the Station in the Trusted Station list. 2. Click the Edit button. The address will be copied to the "Ad- 3. Edit the address (MAC or physical address) as required. 4.

  • Page 30: Password Screen

    Password Screen The password screen allows you to assign a password to the IAD-200 / IAD-200W. Enter the existing password in this field. Old Password New password Enter the new password here. Re-enter the new password here. Verify password You will be prompted for the password when you connect, as shown below. •...

  • Page 31: Chapter 4 Pc Configuration

    Chapter 4 PC Configuration This Chapter details the PC Configuration required on the local ("Internal") LAN. Overview For each PC, the following may need to be configured: • TCP/IP network settings • Internet Access configuration • Wireless configuration Windows Clients This section describes how to configure Windows clients for Internet access via the IAD-200 / IAD-200W.

  • Page 32: Checking Tcp/Ip Settings - Windows 9X/Me

    Checking TCP/IP Settings - Windows 9x/ME: 1. Select Control Panel - Network. You should see a screen like the following: Figure 13: Network Configuration 2. Select the TCP/IP protocol for your network card. 3. Click on the Properties button. You should then see a screen like the following. Figure 14: IP Address (Win 95) Ensure your TCP/IP settings are correct, as follows: Using DHCP...
  • Page 33 • On the Gateway tab, enter the IAD-200 / IAD-200W's IP address in the New Gateway field and click Add, as shown below. Your LAN administrator can advise you of the IP Address they assigned to the IAD-200 / IAD-200W. •...

  • Page 34: Checking Tcp/Ip Settings - Windows Nt

    Checking TCP/IP Settings - Windows NT4.0 1. Select Control Panel - Network, and, on the Protocols tab, select the TCP/IP protocol, as shown below. Figure 17: Windows NT4.0 - TCP/IP 2. Click the Properties button to see a screen like the one below.
  • Page 35 Figure 18: Windows NT4.0 - IP Address 3. Select the network card for your LAN. 4. Select the appropriate radio button - Obtain an IP address from a DHCP Server or Specify an IP Address, as explained below. Obtain an IP address from a DHCP Server This is the default Windows setting.
  • Page 36 Figure 19 - Windows NT4.0 - Add Gateway 2. The DNS should be set to the address provided by your ISP, as follows: • Click the DNS tab. • On the DNS screen, shown below, click the Add button (under DNS Service Search Order), and enter the DNS provided by your ISP.

  • Page 37: Checking Tcp/Ip Settings - Windows

    Checking TCP/IP Settings - Windows 2000: 1. Select Control Panel - Network and Dial-up Connection. 2. Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Figure 21: Network Configuration (Win 2000) 3.
  • Page 38 5. Ensure your TCP/IP settings are correct, as described below. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the IAD-200 / IAD-200W will act as a DHCP Server.

  • Page 39: Checking Tcp/Ip Settings - Windows Xp

    Checking TCP/IP Settings - Windows XP 1. Select Control Panel - Network Connection. 2. Right click the Local Area Connection and choose Properties. You should see a screen like the following: Figure 23: Network Configuration (Windows XP) 3. Select the TCP/IP protocol for your network card. 4.
  • Page 40 Figure 24: TCP/IP Properties (Windows XP) 5. Ensure your TCP/IP settings are correct. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the IAD-200 / IAD-200W will act as a DHCP Server.

  • Page 41: Internet Access

    Internet Access To configure your PCs to use the IAD-200 / IAD-200W for Internet access: • Ensure that the Internet connection is functional. • Use the following procedure to configure your Browser to access the Internet via the LAN, rather than by a Dial-up connection. For Windows 9x/ME/2000 1.

  • Page 42: Macintosh Clients

    Macintosh Clients From your Macintosh, you can access the Internet via the IAD-200 / IAD-200W. The proce- dure is as follows. 1. Open the TCP/IP Control Panel. 2. Select Ethernet from the Connect via pop-up menu. 3. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank.

  • Page 43: Wireless Station Configuration (Iad-200W Only)

    Wireless Station Configuration (IAD-200W only) This section applies to all Wireless stations wishing to use the IAD-200W's Access Point, regardless of the operating system which is used on the client. To use the Wireless Access Point in the IAD-200W, each Wireless Station must have compati- ble settings, as follows: Mode The mode must be set to Infrastructure (rather than Ad-hoc)

  • Page 44: If Wireless Security Is Disabled

    Figure 26 Wireless Networks (Windows XP) If the "Broadcast SSID" setting on the IAD-200W has been disabled, its SSID will NOT be listed. See the following section "If the SSID is not listed" for details of dealing with this situa- tion.

  • Page 45: If Using Wep Data Encryption

    To connect: • Check the checkbox Allow me to connect to the selected wireless network, even though it is not secure. • The Connect button will then be available. Click the Connect button, and wait a few seconds for the connection to be established. If using WEP Data Encryption If WEP data encryption has been enabled on the IAD-200W, Windows will detect this, and show a screen like the following.
  • Page 46 Figure 29: Advanced - Wireless Networks Select the SSID for the IAD-200W, and click Configure, to see a screen like the following: Figure 30: Wireless Network Properties - WEP Configure this screen as follows: • Set Network Authentication to match the IAD-200W. (If the setting on the IAD-200W is "Auto", then either Open or Shared can be used.) •...
  • Page 47 • For the Network key and Confirm network key, enter the default key value used on the IAD-200W. (Windows will determine if 64bit or 128bit encryption is used.) • The Key index must match the default key index on the IAD-200W. The default value is •...
  • Page 48 If using WPA-PSK Data Encryption (IAD-200W only) If WPA-PSK data encryption has been enabled on the IAD-200W, it does not matter which network is selected on the screen below. Just click the Advanced button. Figure 32: Wireless Networks (Windows XP) You will then see a screen like the example below.
  • Page 49 Figure 34: Wireless Network Properties- WPA-PSK Configure this screen as follows: • Set Network Authentication to WPA-PSK. • For Data Encryption, select TKIP. • For the Network key and Confirm network key, enter the network key (PSK) used on the IAD-200W.
  • Page 50 Figure 35: Preferred Networks Click OK to establish a connection to the IAD-200W. If the SSID is not listed (IAD-200W only) If the "Broadcast SSID" setting on the IAD-200W has been disabled, its SSID will NOT be listed on the screen below. Figure 36: Wireless Networks (Windows XP) In this situation, you need to obtain the SSID from your network administrator, and then follow this procedure:...
  • Page 51 2. Click the Add button. You will see a screen like the example below. 3. Configure this screen as follows: • Enter the correct SSID, as used on the IAD-200W. Remember the SSID is case- sensitive, so be sure to match the case, not just the spelling. •...
  • Page 52 • If using data encryption (WEP or WPA-PSK), enter the key used on the IAD-200W. See the preceding sections for details of WEP and WPA-PSK. • Uncheck the options. The key is provided for me automatically and this is a computer- to-computer (ad hoc) network.

  • Page 53: Chapter 5 Advanced Features

    Chapter 5 Advanced Features This Chapter explains when and how to use the IAD-200 / IAD-200W's "Advanced" Features. Overview The following advanced features are provided: • Internet: • • Special Applications • URL filter • Dynamic DNS • Firewall Rules •...

  • Page 54: Special Applications

    This feature, if enabled, allows the DMZ computer on your LAN to be exposed to all users on the Internet. • This allows almost any application to be used on the "DMZ PC". • The "DMZ PC" will receive all "Unknown" connections and data. •...

  • Page 55: Url Filter

    Data - Special Applications Screen Checkbox Use this to Enable or Disable this Special Application as required. Name Enter a descriptive name to identify this Special Application. • Type - Select the protocol (TCP or UDP) used when you receive data Incoming from the special application or service.
  • Page 56 Data - URL Filter Screen Current Filter Strings Current Filter The list contains the current list of items to block. Strings • • • To add to the current list, type the word or domain name you want to Add Filter String block into the field provided, then click the Add button.
  • Page 57 Trusted PC Enable this to allow one computer to have unrestricted access to the Allow Trusted Internet. For this PC, the URL filter will be ignored. If enabled, you must select the PC to be the trusted PC. Trusted PC Select the PC to be the Trusted PC.

  • Page 58: Dynamic Dns (Domain Name Server)

    Dynamic DNS (Domain Name Server) This free service is very useful when combined with the Virtual Server feature. It allows Internet users to connect to your Virtual Servers using a URL, rather than an IP Address. This also solves the problem of having a dynamic IP address. With a dynamic IP address, your IP address may change whenever you connect, which makes it difficult to connect to you.
  • Page 59 DDNS Data Host Name Enter the domain name allocated to you by the DDNS Service. If you have more than one name, enter the name you wish to use. Enter your Username for the DDNS Service. (TZO.com uses your E- User Name mail address.) Password...

  • Page 60: Firewall Rules

    Firewall Rules The Firewall Rules screen allows you to define "Firewall Rules" which can allow or prevent certain traffic. "Traffic" means incoming connection attempts, not packets. By default: • All Outgoing traffic is permitted. • All Incoming traffic is denied. Because of this default behavior, any Outgoing rules will generally Block traffic, and Incom- ing rules will generally Allow traffic.
  • Page 61 Action The action performed on connections which are covered by this rule. The PC or Server on your LAN to which traffic covered by this rule LAN Server will be sent. WAN Users The WAN IP address or addresses covered by this rule. Indicates whether or not connections covered by this rule should be logged.

  • Page 62: Incoming Rules (Inbound Services)

    Incoming Rules (Inbound Services) This screen is displayed when the "Add" or "Edit" button for Incoming Rules is clicked. Data - Incoming Rules Screen Inbound Services Select the desired Service. This determines which packets are covered by Service this rule. If necessary, you can define a new Service on the "Services" screen, by defining the protocols and port numbers used by the Service.

  • Page 63: Outgoing Rules (Outbound Services)

    This determines whether packets covered by this rule are logged. Select the desired action. • Always - always log traffic considered by this rule, whether it matches or not. (This is useful when debugging your rules.) • Never - never log traffic considered by this rule, whether it matches or not.
  • Page 64 BLOCK rule. (That is, you wish to allow a subset of traffic which is currently blocked by another rule.) • To define the Schedule used in these selections, use the "Schedule" screen. Select the desired option to determine which PCs are covered by this LAN Users rule: •...

  • Page 65: User-Defined Services

    User-defined Services Services are used when creating Firewall Rules. If you wish to create a firewall rule, but the required service is not listed in the "Service" list, you can use this feature to define the required service or services. Once created, these services will be listed in the "Service"...

  • Page 66: Add/Edit Service

    Add/Edit Service This screen is displayed when the Add or Edit button on the Services screen is clicked. Data - Add/Edit Service Services If editing, this shows the current name of the Service. Name If adding a new service, this will be blank, and you should enter a suitable name.

  • Page 67: Options

    Options This screen allows advanced users to enter or change a number of settings. For normal opera- tion, there is no need to use this screen or change any settings. An example Options screen is shown below. Data - Options Screen Internet •...

  • Page 68: Schedule

    Schedule This Schedule can be used for the Firewall Rules and the URL filter. Data - Schedule Screen Schedule Each day of the week can scheduled independently. Session 1 Two (2) separate sessions or periods can be defined. Session 2 can be left blank if not required.
  • Page 69 light Savings Time adjustment period, and uncheck it at the end of the Daylight Savings period. If you prefer to use a particular NTP server as the primary NTP Use this NTP Server server, check the checkbox "Use this NTP Server" and enter the Server's IP address in the fields provided.

  • Page 70: Virtual Servers

    Virtual Servers This feature, sometimes called Port Forwarding, allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to access a server on your LAN because: • Your Server does not have a valid external IP Address. •...

  • Page 71: Connecting To The Virtual Servers

    • To make it easier for Internet users to connect to your Servers, you can use the "DDNS" feature. This allows Internet users to connect to your Servers with a URL, rather than an IP address. This technology works even if your ISP allocates dynamic IP addresses (IP address is allocated upon connection, so it may change each time you connect).
  • Page 72 Note: From the Internet, ALL Virtual Servers have the IP Address allocated by your ISP.

  • Page 73: Voip

    VoIP To use the VoIP feature requires the following: • Standard Phone A standard analogue Phone must be connected to the Phone socket. • VoIP (SIP Server) Account Generally, you will need a SIP Server account from a VoIP service provider. The account details should include the SIP Register address, SIP Proxy address, SIP register port, SIP Proxy port, username, password, and telephone number.
  • Page 74 VoIP Settings Local Service SIP Local Port This port is used for peer-to-peer (direct) connections to another device, when no SIP server is used. Normally, this should be left at the default value. Any other devices you wish to connect to must use the same port number. SIP - Line 1 Enable Line1 Check this if you wish to connect to a SIP Server.
  • Page 75 SIP register Enter the port used for "Register" connections to the Server above. port Register This sets the "Idle Timeout" for the SIP Server Login. An Idle connec- Expiry Time tion will be terminated after this time period. Enter the desired value. Enter the login name for connections to the SIP Server.
  • Page 76 Display Name Telephone Number Registration Status PSTN Settings Screen This screen has some additional settings related to the use of the PSTN line, assuming the PSTN line is connected, which is strongly recommended. This is the name you chose when you first opened your account. Your "Display Name"...
  • Page 77 PSTN Settings PSTN Relay PSTN Prefix PSTN Fixed Relay PSTN Rollover Use PSTN… The PSTN Relay allows certain calls to be diverted to the PSTN link, even though VoIP is working properly. This PSTN prefix means that any number beginning with this prefix will be diverted to PSTN (the prefix itself is deleted, then the remainder of the number is dialed via PSTN).

  • Page 78: Chapter 6 Advanced Administration

    Chapter 6 Advanced Administration This Chapter explains the settings available via the "Administration" section of the menu. Overview Normally, it is not necessary to use these screens, or change any settings. These screens and settings are provided to deal with non-standard situations, or to provide additional options for advanced users.

  • Page 79: Pc Database

    PC Database The PC Database is used whenever you need to select a PC (e.g. for the "DMZ" PC). • It eliminates the need to enter IP addresses. • Also, you do not need to use fixed IP addresses on your LAN. However, if you do use a fixed IP address on some devices on your LAN, you should enter details of each such device into the PC database, using the PC Database screen.
  • Page 80 Data - PC Database Screen Known PCs This lists all current entries. Data displayed is name (IP Address) type. The "type" indicates whether the PC is connected to the LAN. If adding a new PC to the list, enter its name here. It is best if this Name matches the PC's "hostname".

  • Page 81: Pc Database - Advanced

    PC Database - Advanced This screen is displayed if the "Advanced Administration" button on the PC Database is clicked. It provides more control than the standard PC Database screen. Data - Advanced PC Database Known PCs This lists all current entries. Data displayed is name (IP Address) type. The "type"...
  • Page 82 IP Address Select the appropriate option: • Automatic - The PC is set to be a DHCP client (Windows: "Ob- tain an IP address automatically"). The IAD-200 / IAD-200W will allocate an IP address to this PC when requested to do so. The IP address could change, but normally won't.

  • Page 83: Config File

    Config File This feature allows you to download the current settings from the IAD-200 / IAD-200W, and save them to a file on your PC. You can restore a previously-downloaded configuration file to the IAD-200 / IAD-200W, by uploading it to the IAD-200 / IAD-200W. This screen also allows you to set the IAD-200 / IAD-200W back to its factory default con- figuration.

  • Page 84: Logs

    Logs The Logs record various types of activity on the IAD-200 / IAD-200W. This data is useful for troubleshooting, but enabling all logs will generate a large amount of data and adversely affect performance. Since only a limited amount of log data can be stored in the IAD-200 / IAD-200W, log data can also be E-mailed to your PC.
  • Page 85 Buttons There are three (3) buttons • • • Logs Use these checkboxes to determine which events are included in Include (Checkboxes) the log. Checking all options will increase the size of the log, so it is good practice to disable any events which are not really re- quired.

  • Page 86: E-Mail

    E-mail This screen allows you to E-mail Logs and Alerts. A sample screen is shown below. Data - E-mail Screen E-Mail Notification Check this box to enable this feature. If enabled, the E-mail address Turn E-mail Notification on information (below) must be provided. Enter the E-mail address the Log is to be sent to.
  • Page 87 Password If you have enabled "My SMTP Mail Server requires authentication" above, enter the password required to login to your SMTP Server. E-mail Alerts Send E-mail alerts You can choose to have alerts E-mailed to you, by checking the immediately desired checkboxes.

  • Page 88: Diagnostics

    Diagnostics This screen allows you to perform a "Ping" or a "DNS lookup". These activities can be useful in solving network problems. An example Network Diagnostics screen is shown below. Data - Network Diagnostics Screen Ping Ping this Enter the IP address you wish to ping. The IP address can be on your IP Address LAN, or on the Internet.

  • Page 89: Remote Administration

    Remote Administration If enabled, this feature allows you to manage the IAD-200 / IAD-200W via the Internet. Figure 62: Remote Administration Screen Data - Remote Administration Screen Remote Administration Enable Remote Check to allow administration/management via the Internet. (To connect, see below). Management If Disabled, this device will ignore Administration connection attempts from the Internet.
  • Page 90 For security, you should restrict access to as few external IP ad- dresses as practical. To connect from a remote PC via the Internet 1. Ensure your Internet connection is established, and start your Web Browser. 2. In the "Address" bar, enter "HTTP://" followed by the Internet IP Address of the IAD-200 / IAD-200W.

  • Page 91: Routing

    Routing Overview • If you don't have other Routers or Gateways on your LAN, you can ignore the "Routing" page completely. • If the IAD-200 / IAD-200W is only acting as a Gateway for the local LAN segment, ignore the "Routing" page even if your LAN has other Routers. •...

  • Page 92: Configuring Other Routers On Your Lan

    Data - Routing Screen RIP Direction Select the desired RIP Direction. RIP Version Choose the RIP Version for the Server. Static Routing This list shows all entries in the Routing Table. Static Routing Table Entries • • Buttons Add a new entry to the Static Routing table, using the data shown in the "Properties"...

  • Page 93: Static Routing - Example

    Local Router The local router is the Router installed on the same LAN segment as the IAD-200 / IAD-200W. This router requires that the Default Route is the IAD-200 / IAD-200W itself. Typically, routers have a special entry for the Default Route. It should be configured as follows. Destination IP Address Network Mask Gateway IP Address...
  • Page 94 Metric Entry 2 (Segment 2) Destination IP Address Network Mask Gateway IP Address Metric For Router A's Default Route Destination IP Address Network Mask Gateway IP Address For Router B's Default Route Destination IP Address Network Mask Gateway IP Address Router) 192.168.2.0 255.255.255.0 (Standard Class C)

  • Page 95: Upgrade Firmware

    Upgrade Firmware The firmware (software) in the IAD-200 / IAD-200W can be upgraded using your Web Browser. You must first download the upgrade file, then select Upgrade Firmware on the Administra- tion menu. You will see a screen like the following. To perform the Firmware Upgrade: 1.

  • Page 96: Chapter 7 Operation And Status

    Chapter 7 Operation and Status This Chapter details the operation of the IAD-200 / IAD-200W and the status screens. Operation Once both the IAD-200 / IAD-200W and the PCs are configured, operation is automatic. However, there are some situations where additional Internet configuration may be required. Refer to Chapter 5 - Advanced Features for further details.
  • Page 97 Data - Status Screen System Device Name Firmware Version ADSL Modem Status DownStream Connection Speed UpStream Connection Speed VC 1 Status ADSL Details Figure 66: Status Screen The current name of the Router. This name is also the "hostname" for users with an "@Home" type connection. The version of the current firmware installed.
  • Page 98 Internet (VC1) Connection Method Displays the current connection method, as set in the Setup Wizard. This indicates the current status of the Internet Connection Connection Status • • • If there is an error, you can click the "Connection Details" button to find out more information.
  • Page 99 devices currently on the network. Update the data displayed on screen. Refresh Screen...

  • Page 100: Connection Status - Pppoe & Pppoa

    Connection Status - PPPoE & PPPoA If using PPPoE (PPP over Ethernet) or PPPoA (PPP over ATM), a screen like the following example will be displayed when the "Connection Details" button is clicked. Data - PPPoE/PPPoA Screen Connection Time PPPoE Link Status Negotiation IP Address Network Mask...

  • Page 101: Connection Details - Dynamic Ip Address

    Connection Details - Dynamic IP Address If your access method is "Direct" (no login), with a Dynamic IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 68: Connection Details - Fixed/Dynamic IP Address Data - Dynamic IP address Internet IP Address...
  • Page 102 IAD-200 / IAD-200W, clicking the "Renew" button will attempt to re-establish the connection and obtain an IP Address from the ISP's DHCP Server. Close Close this window.

  • Page 103: Connection Details - Fixed Ip Address

    Connection Details - Fixed IP Address If your access method is "Direct" (no login), with a fixed IP address, a screen like the follow- ing example will be displayed when the "Connection Details" button is clicked. Figure 69: Connection Details - Fixed/Dynamic IP Address Data - Fixed IP address Screen Internet IP Address...

  • Page 104: Using Voip

    Using VoIP VoIP cannot be used until configuration has been completed. See the VoIP topic in Chapter 5 - Advanced Features for details of VoIP configuration. Normal Operation • Your Internet connection should be configured to keep the Internet connection active as much as possible (Keep Alive).

  • Page 105: Appendix A Troubleshooting

    Appendix A Troubleshooting This Appendix covers the most likely problems and their solutions. Overview This section covers some common problems that may be encountered while using the IAD-200 / IAD-200W and some possible solutions to them. If you follow the suggested steps and the IAD-200 / IAD-200W still does not function properly, contact your dealer for further advice.

  • Page 106: Wireless Access (Iad-200W Only)

    Problem 2: Some applications do not run properly when using the IAD-200 / IAD- 200W. The IAD-200 / IAD-200W processes the data passing through it, so it is not Solution 2: transparent. For incoming connections, you must use the Virtual Server or Firewall Rules to specify the PC which will receive the incoming traffic.
  • Page 107 stations. This will mean high access speed is only possible when close to the IAD-200W.

  • Page 108: Appendix B About Wireless Lans (Iad-200W Only)

    Appendix B About Wireless LANs This Appendix provides some background information about using Wireless LANs (IAD-200W only). Modes Wireless LANs can work in either of two (2) modes: • Ad-hoc • Infrastructure Ad-hoc Mode Ad-hoc mode does not require an Access Point or a wired (Ethernet) LAN. Wireless Sta- tions (e.g.

  • Page 109: Channels

    Channels The Wireless Channel sets the radio frequency used for communication. • Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channels are available.

  • Page 110: Wireless Lan Configuration

    Wireless LAN Configuration To allow Wireless Stations to use the Access Point, the Wireless Stations and the Access Point must use the same settings, as follows: On client Wireless Stations, the mode must be set to "Infrastructure". Mode (The Access Point is always in "Infrastructure" mode.) SSID (ESSID) Wireless Stations should use the same SSID (ESSID) as the Access Point they wish to connect to.
