Follow these steps to install the battery in the DLC cabinet.
STEP 1.
Open battery compartment.
Action
Insert the blade of a flat screwdriver or
dime into the slot on the battery
compartment screw and turn one-quarter
turn to release the door. You will see the
connector wires.
STEP 2.
Connect wires to battery.
Action
Connect the red wire to the positive
terminal on the battery and the black wire
to the negative terminal on the battery.
Installation and Operations Manual
Device/Illustration
Device/Illustration
AT&T Proprietary (Internal Use Only)
—53—
