6.2.9.1 Discovering and Registering the Takeover Module

Follow these steps to discover and register the takeover module:
Step Action
1. Place the DLC into Discovery Mode in DLD.
2. Make the takeover module discoverable by inserting the batteries.
Alternate Method: Press the tamper switch located in the middle of the board.
3. Confirm that the takeover module has been discovered in DLD.
4. Label the takeover module and zones in DLD.

6.2.9.2 Installation and Mounting Guidelines

Screw the mounting bracket to the wall with the included hardware. The bracket and
Takeover Module must be mounted within RF range of the DLC, as shown in Figure 66.
NOTE: Signals will not be received if the Takeover Module is not within range of the
DLC.
Installation and Operations Manual

Figure 66: Takeover Module Mounted
