5.1.3.4

Setting the operating mode and runtime parameters

The parameter values set are preset in the JOB and can be modified if necessary.
Operating
element
Item No.: 099-004934-EWM01
Action Result
Select operating mode:
n x
Select welding parameter:
n x
The selected parameter is shown on the display
Set the parameter chosen
Functional characteristics
Machine control – Operating elements
NOTE
Non-latched
Latched
Spots
Interval
Set gas post-flow time "GnS"
(0.0 s to 10.0 s)
Set wire burn-back time "drb" (-50% to 50%)
Spot/interval time "t1" (0.1 s to 5.0 s)
Interval/pause "t2" (0.1 s to 2.0 s)
41
