EWM WEGA 401 Operating Instructions Manual page 23

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Step switch, "coarse" welding voltage not applicable with WEGA 351
Coolant tank only for machines fitted with water cooling (DW)
Item No.: 099-004934-EWM01
0
Wire feed unit
Lifting lug
Carrying handle
Main switch, machine on/off
Step switch, welding voltage "coarse"
Step switch, welding voltage
Connection socket, workpiece lead
"Hard" choke tapping
Connection socket, workpiece lead
"Medium" choke tapping
Connection socket, workpiece lead
Choke tapping "soft"
Conveyor rolls, fixed castors
Conveyor rolls, guide castors
Cooling air inlet
Signal light, Functional error
On when excess temperature detected
Key button, automatic cut-out of coolant pump
Press to reset a triggered fuse
Coolant tank cap
Coolant tank
Machine description
WEGA 351, 401, 451, 501, 601 D
NOTE
23
