VLT AutomationDrive FC 300 Operating
Instructions
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital Output A
[81] SL Digital Output B
[82] SL Digital Output C
[83] SL Digital Output D
[84] SL Digital Output E
[85] SL Digital Output F
[120] Local reference active
[121] Remote reference active
[122] No alarm
[123] Start command active
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2], Relay 4 [3], Relay 5 [4], Relay 6 [5], Relay 6 [5], Relay 7 [6], Relay 8 [7], Relay 9 [8])
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] VLT running
See par. group 13-4*. If Logic Rule 1 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. 13-52 SL Controller Action . The output will go high whenever the Smart Logic Action [38]
Set dig. out. A high is executed. The output will go low whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [33]
dig. out. A low is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [34]
dig. out. A low
is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [35]
dig. out. A low
is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [36]
dig. out. A low is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [37]
dig. out. A low is executed.
Output is high when par. 3-13 Reference Site
Linked to hand auto at the same time as the LCP is in Hand on mode.
Reference Site = Remote
Output is high when par. 3-13
LCP is in [Auto on] mode.
Output is high when no alarm is present.
Output is high when there is an active Start command (i.e. via digital input bus connection or [Hand
on] or [Auto on]), and no Stop or Start command is active.
Output is high when the frequency converter is running counter clockwise (the logical product of
the status bits 'running' AND 'reverse').
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Hand on]).
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Auto on]).
Function:
MG.33.AC.02 - VLT is a registered Danfoss trademark
. The input will go high whenever the Smart Logic Action [39]
. The input will go high whenever the Smart Logic Action [40]
. The input will go high whenever the Smart Logic Action [41]
. The input will go high whenever the Smart Logic Action [42]
. The input will go high whenever the Smart Logic Action [43]
= [2] Local or when par. 3-13
Linked to hand/auto
[1] or
4 How to Programme
4
Set
Set
Set
Set
Set
Reference Site = [0]
[0] while the
