Danfoss VLT AutomationDrive FC 300 Operating Instructions Manual page 22

3 How to Install
3
Illustration 3.13: Motor connection frame size C1 and C2 (IP 21/ NEMA
Type 1 and IP 55/66/ NEMA Type 12)
Illustration 3.15: Cable entry holes for frame size B1. The suggested
use of the holes are purely recommendations and other solutions are
possible.
Illustration 3.16: Cable entry holes for frame size B2. The suggested
use of the holes are purely recommendations and other solutions are
possible.
Term. no. 96
U
U1
W2
U1
1) Protected Earth Connection
22
97 98 99
Motor voltage 0-100% of mains voltage.
V W PE 1)
3 wires out of motor
V1 W1 Delta-connected
1)
PE
U2 V2 6 wires out of motor
V1 W1 1) Star-connected U2, V2, W2
PE
U2, V2 and W2 to be interconnected separately.
MG.33.AC.02 - VLT is a registered Danfoss trademark
®
VLT AutomationDrive FC 300 Operating
Illustration 3.14: Motor connection for frame size C3 and C4.
Illustration 3.17: Cable entry holes for frame size C1. The suggested
use of the holes are purely recommendations and other solutions are
possible.
Illustration 3.18: Cable entry holes for frame size C2. The suggested
use of the holes are purely recommendations and other solutions are
possible.
Instructions
