4.4 Parameter Lists

Changes during operation
"TRUE" means that the parameter can be changed while the frequency converter is in operation and "FALSE" means that the it must be stopped before
a change can be made.
4-Set-up
'All set-up': the parameters can be set individually in each of the four set-ups, i.e. one single parameter can have four different data values.
'1 set-up': data value will be the same in all set-ups.
Conversion index
This number refers to a conversion figure used when writing or reading to and from the frequency converter.
Conv. index 100 67
Conv. factor 1 1/60 1000000
Data type Description
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible String
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
Design Guide
See the frequency converter
Parameters for the frequency converter are grouped into various parameter groups for easy selection of the correct parameters for optimized operation
of the frequency converter.
0-xx Operation and Display parameters for basic frequency converter settings
1-xx Load and Motor parameters, includes all load and motor related parameters
2-xx Brake parameters
3-xx References and ramping parameters, includes DigiPot function
4-xx Limits Warnings, setting of limits and warning parameters
5-xx Digital inputs and outputs, includes relay controls
6-xx Analog inputs and outputs
7-xx Controls, setting parameters for speed and process controls
8-xx Communication and option parameters, setting of FC RS485 and FC USB port parameters.
9-xx Profibus parameters
10-xx DeviceNet and CAN Fieldbus parameters
13-xx Smart Logic Control parameters
14-xx Special function parameters
6 5 4 3
100000 10000 1000 100
for further information about data types 33, 35 and 54.
MG.33.AC.02 - VLT is a registered Danfoss trademark
2 1 0 -1 -2
10 1 0.1 0.01
4 How to Programme
-3 -4 -5 -6
0.001 0.0001 0.00001 0.000001
Type
Int8
Int16
Int32
Uint8
Uint16
Uint32
VisStr
N2
V2
TimD
