VLT AutomationDrive FC 300 Operating
Instructions
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
[20] * Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
3-17 Reference Resource 3
Option:
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] * Local bus reference
[20] Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
5-00 Digital I/O Mode
Option:
[0] * PNP
[1] NPN
NB!
Once this parameter has been changed, it must be activated by performing a power cycle.
This parameter cannot be adjusted while the motor is running.
5-01 Terminal 27 Mode
Option:
[0] * Input
[1] Output
Please not that this parameter cannot be adjusted while the motor is
running.
5-02 Terminal 29 Mode
Option:
[0] * Input
[1] Output
This parameter is available for FC 302 only.
This parameter cannot be adjusted while the motor is running.
Function:
Select the reference input to be used for the third reference signal. par. 3-15
1 Reference Resource 2
, par. 3-16 and par. 3-17
reference signals. The sum of these reference signals defines the actual reference.
Function:
Digital inputs and programmed digital outputs are pre-programmable for operation either in PNP or
NPN systems.
Action on positive directional pulses (↕). PNP systems are pulled down to GND.
Action on negative directional pulses (↕). NPN systems are pulled up to + 24 V, internally in the
frequency converter.
Function:
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
Function:
Defines terminal 29 as a digital input.
Defines terminal 29 as a digital output.
MG.33.AC.02 - VLT is a registered Danfoss trademark
4 How to Programme
Reference Resource
Reference Resource 3
define up to three different
4
