VLT AutomationDrive FC 300 Operating
Instructions
1-22 Motor Voltage
Range:
400. V* [10. - 1000. V]
1-23 Motor Frequency
Range:
50. Hz* [20 - 1000 Hz]
1-24 Motor Current
Range:
7.20 A* [0.10 - 10000.00 A]
NB!
This parameter cannot be adjusted while the motor is running.
1-25 Motor Nominal Speed
Range:
1420. RPM* [100 - 60000 RPM]
NB!
This parameter cannot be changed while the motor is running.
5-12 Terminal 27 Digital Input
Option:
NB!
Four sizes down, one size up from nominal VLT rating.
Function:
Enter the nominal motor voltage according to the motor nameplate data. The default value corre-
sponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Function:
Min - Max motor frequency: 20 - 1000 Hz.
Select the motor frequency value from the motor nameplate data. If a value different from 50 Hz
or 60 Hz is selected, it is necessary to adapt the load independent settings in par. 1-50
Magnetisation at Zero Speed
to par. 1-53
V motors, set the nameplate data for 230 V/50 Hz. Adapt par. 4-13
[RPM] Maximum Reference
and par. 3-03
Function:
Enter the nominal motor current value from the motor nameplate data. This data is used for cal-
culating motor torque, motor thermal protection etc.
Function:
Enter the nominal motor speed value from the motor nameplate data. This data is used for calcu-
lating automatic motor compensations.
Function:
Select the function from the available digital input range.
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
MG.33.AC.02 - VLT is a registered Danfoss trademark
4 How to Programme
Model Shift Frequency
. For 87 Hz operation with 230/400
Motor Speed High Limit
to the 87 Hz application.
4
Motor
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[8]
[9]
[10]
[11]
[12]
[13]
41
