38 MDS 9810 Installation and Operation Guide
For DCE operation, the timer specifies how long to wait after the RTS
line goes high before asserting the CTS line. A timer value of zero
means that the CTS line will always be asserted (unless the radio is
attempting to throttle back data as part of normal flow control opera-
tion).
For CTS Key operation (see the
how long to wait after asserting the CTS line before sending data out the
port. A timer value of zero means that data will be sent
DATA INTERFACE
out the data port without imposing a key-up delay. (Other delays may be
in effect from other radio operating parameters.)

CTSHOLD [0-6000]

Used in
DEVICE CTS KEY
milliseconds that CTS remains present following transmission of the
last character out the RXD pin of the
time" can be used to prevent squelch tail data corruption when inter-
working with other radios.
The setting can range from 0 to 6000 (i.e., 6 seconds). The
CTSHOLD
default value is 0, which means that CTS will drop immediately after the
last character is transmitted. If the command is entered when the radio
is in mode, the response
DEVICE DCE

DEVICE [DCE, CTS KEY]

The command sets or displays the device behavior of the radio.
DEVICE
The command parameter is either
The default selection is
RTS, subject to the CTS programmable delay time. Keying is stimulated
by the input of characters at the data port. Hardware flow control is
implemented by dropping the CTS line if data arrives faster than it can
be transmitted.
If is selected, the radio is assumed to be controlling another
CTS KEY
radio, such as in a repeater system. The RTS line is ignored and the CTS
line is used as a keyline control for the other radio. CTS is asserted
immediately after the receipt of RF data, but data will not be sent out the
port until after the CTS programmable delay time has
DATA INTERFACE
expired. (This gives the other radio time to key.)
Following transmission of the last byte of data, CTS will remain
asserted for the duration specified by the
should be set sufficiently high.
command), the timer specifies
DEVICE
mode, this command sets the amount of time in
DATA INTERFACE
CTSHOLD N/A
or
DCE CTS KEY
. In this mode, CTS will go high following
DCE
CTSHOLD
port. This "hold
will be displayed.
.
command.
CTSHOLD
