used for programming instead of the
arrangement, Pin 23 of the HHT cable must be grounded to enable
the diagnostic channel. (See Table 15 on Page 59.)
Figure 22. Hand-Held Terminal Connected to the Transceiver
2. When the HHT is connected, it runs through a brief self-check, end-
ing with a beep. After the beep, press
">" prompt.

6.2 Hand-Held Terminal Setup

The following is a set of instructions for re-initializing an HHT for use
with the transceiver. These steps may be required if the HHT was previ-
ously used with a different radio, or if the HHT default settings have
been inadvertently altered.
1. Plug the HHT into the
mode by pressing the
The display shown in Figure 23 will appear.
MDS 9810 Installation and Operation Guide
DIAG(NOSTICS)
Invisible place holder
ENTER
connector. Enable the setup
DIAG(NOSTICS)
,
and
SHIFT CTRL SPACE
jack. With this
to receive the ready
keys in sequence.
29
