5.0 OPERATION

5.1 Initial Start-up

In-service operation of the transceiver is completely automatic. Once
the unit has been properly installed and configured, operator actions are
limited to observing the LED status indicators for proper operation.
If all parameters are correctly set, operation of the radio can be started
by following these steps:
1. Apply primary power to the radio.
2. Observe the transceiver LED status panel (Figure 21) for the proper
indications. Table 4 provides a complete explanation of the LED
functions.
In a normally operating system, the following LED indications will
be seen within 16 seconds of start-up:
• lamp lit continuously
PWR
• lamp lit continuously
SYNC
• Remote radio
(
( ) with the master station
RXD
Figure 21. LED Status Indicators
Table 4. LED Status Indicators
LED Name Description
PWR • Continuous—Power is applied to the radio; no problems detected.
• Flashing 5 times per second—Fault indication.
See Section 7.0, TROUBLESHOOTING (beginning on Page 50).
• Flashing once every 4 seconds—radio is in Sleep mode.
SYNC Lights continuously to indicate the radio is receiving/sending
synchronization frames. Within 16 seconds of power-up, this LED
should be lit continuously.
TXD Indicates EIA-232 space (logic high) signal input to the DB-25
connector.
RXD Indicates EIA-232 space (logic high) signal output from the DB-25
connector.

5.2 Performance Optimization

After the basic operation of the radio has been checked, you may wish
to optimize its performance using some of the suggestions given here.
The effectiveness of these techniques will vary with the design of your
system and the format of the data being sent.
s transmitting data (
) TXD
Invisible place holder
PWR SYNC TXD RXD
) and receiving data
