48 MDS 9810 Installation and Operation Guide
Note that when TDD is enabled (
on both data throughput and latency. Data throughput is roughly cut in
half. Worst case data latency is increased by two hoptimes. The effect in
seamless mode (
BUFF ON
10.
Table 10. Hoptime Setting vs. Delay (
HOP TIME
XSHORT
16
20
25
32
SHORT
NORMAL
LONG

TEMP

This command displays the internal temperature of the transceiver in
degrees Celsius. (Note that the radio is specified to operate in an envi-
ronment between –30 C° and +60 C°). This internal reading may be
higher than the outside temperature by several degrees.

TX [xxxx]

This command sets or displays the test transmit frequency used in place
of hopping whenever the radio is in Setup mode. The test transmit fre-
quency can be reprogrammed to any value between 902.025 MHz and
927.975 MHz, inclusive. The factory default settings are listed below
and have been selected to be non-intrusive to normal system operation.
902.025 MHz
UNIT [10000–65000]
This command sets the unit addressing for network-wide diagnostics.
The unit address is factory programmed to the last four digits of the
serial number. If re-programmed in the field, the entry must consist of
five digits between 10000 and 65000.
), there is a significant impact
TDD ON
) is even more pronounced, as shown in Table
BUFF ON
MINIMUM DELAY
33 ms
39 ms
43 ms
48 ms
55 ms
63 ms
103 ms
183 ms
Default Transmit Frequencies
Master Remote
927.975 MHz
—"Seamless Mode")
MAXIMUM DELAY
66 msec
78 ms
86 ms
96 ms
110 ms
126 msec
206 msec
366 msec
MDS 05-3301A01, Rev. C
