Drive The VLT LonWorks option provides 16 output
variables to the network containing important
Feedback to
drive and motor feedback data. Feedback data
Network
is sent when there is a change in value. The
VLT LonWorks option will only transmit bound
network variables. Since some data changes
continuously, the transmission rate of those
variables is limited. Min send time specifies
the minimum time between transmissions of
variables.
VLT 5000 parameters are shown in parenthesis, where applicable.
MG.60.N1.22 - VLT is a registered Danfoss trademark
Function SNVT type
Drive status SNVT_state
Drive output 1 SNVT_lev_percent
1)
Current SNVT_amp
Energy SNVT_elec_kwh
1)
Power SNVT_power_kilo
Statusword SNVT_state
Drive output 3 SNVT_freq_hz
Output voltage SNVT_volt
Digital input SNVT_state
Alarm SNVT_state
Warning 1 SNVT_state
Warning 2 SNVT_state
DC voltage SNVT_volt
Motor therm. Status SNVT_lev_cont
Inverter therm. Status SNVT_lev_cont
Analog input SNVT_volt
Term. 53
Analog input SNVT_volt
Term. 54
Analog input SNVT_amp_mil
Term. 60
1)
Running hours SNVT_time_hour
Feedback SNVT_lev_percent
Frequency SNVT_freq_hz
1)
Drive speed SNVT_lev_percent
1)
Output voltage SNVT_volt
Part of the LonMark Functional Profile for
1)
Variable Speed Drive 6010 version 1.1
VLT ® 5000 / VLT
The Drive Outputs (1, 2, or 3) will have a
maximum time between transmission set by the
Max send time. This function acts as a transmit
heartbeat and allows a controller node to
determine the health of the controller/VLT
connection. The Max send time function is
disabled when the configuration network
variable nciMaxsendT is not configured or is set
to "0."
Variable Name
nvoDrvStatus
nvoOutputPcnt
nvoDrvCurnt
nvoDrvEnrg
nvoDrvPwr
nvoStatusWord
nvoOutputHz
nvoVoltage
nvoDigitlInput
nvoAlarmWord
nvoWarning1
nvoWarning2
nvoDCVolt
nvoTempMtr
nvoTempInvrtr
nvoAnalog1
nvoAnalog2
nvoAnalog3
nvoDrvRunHours
nvoFeedback
nvoOutputHz1
nvoDrvSpeed
nvoDrvVolt
Network Variable Outputs from VLT
® 6000 HVAC / VLT ® 8000 AQUA
Units Max
16 Boolean NA
0.005% 163.835
0.1 amps 3276.7
1 kWh 65,535
0.1 kW 6553.5
16 Boolean NA
0.1 Hz 6553.5
0.1 V 3276.7
16 Boolean NA
16 Boolean NA
16 Boolean NA
16 Boolean NA
0.1 V 3276.7
0.5 % 100
0.5 % 100
0.1 V 10
0.1 V 10
0,1 mA 20
1 Hour 65534
0.01% 100.000
0.1 Hz 6553.5
0.01% 100
0.1 V 3276.7
Min
NA
–
163.840
0
0
0
NA
0
–3276.8
NA
NA
NA
NA
0
0
0
0
0
0
0
0
0
0
0
