3. Click on the measurements that you want to deactivate.
The check ( ) preceding the items is cleared.
– or –
Click on a deactivated measurement.
The measurement is activated and a check ( ) appears in front of the item.
4. Click on the "OK" button.
The "Select Optional Measurements - [Application name]" window closes.
2.6.3

Saving a (new) application

1. Click on the "Save As" menu item in the "Application" menu in the
"ANT-20 NEXT - [Application]" window.
The "Save Application" window opens.
Fig. O-38
2. Under "Directories:", select the path under which the new application is to be saved.
3. Enter the file name for the new application (max. 8 characters) in the "File Name:" text box.
4. Click on the "Save" button.
The new application will be saved under the file name you entered.
2.6.4

Saving an (edited) application

⇒ Click on the "Save" menu item in the "Application" menu in the
"ANT-20 NEXT - [Application]" window.
The application will be saved under its existing file name.
Note: Applications that have been provided by Wavetek Wandel Goltermann cannot be
O-28
"Save Application" window
overwritten. In such cases, the "Save" menu item has the same effect as the "Save As"
menu item, i.e. you will be prompted to enter a new file name.
