2.6.2

Customizing an application

You can customize applications at two levels:
• Customize basic parameters (Basics)
• Customize the Expert setup (Details)
– Customize diagnostic evaluations
– Customize description of possible error cause (Possible Causes)
– Set the measurement parameters (gate times, etc.)
– Deactivate measurements
Customizing the basic parameters (Basics)
The application that you want to customize is loaded.
1. Click on the "Edit" menu item in the "Application" menu in the "ANT-20 NEXT - [Application]"
window.
The "Edit Basics - [Application name]" window opens.
Fig. O-27
2. Adjust the settings in this window to meet your requirements.
3. Click on the "OK" button.
Customizing the Expert setup (Details)
⇒ Click on the"ExpertMode" menu item in the "Administration" menu of the
"ANT-20 NEXT - [Application]" window.
The item is marked with a check ( ).
Four buttons are now shown in the "Edit Basics - [Application name]" window; these can be
used for customizing the details of the applications.
Fig. O-28
O-22
"Edit Basics - [Application name]" window
"Administration" menu
