ANT-20 NEXT
2.5.3

Loading a report

To display a report for evaluation, proceed as follows:
1. Click on the "Load" menu item in the "Report" menu in the "ANT-20 NEXT - [Application]"
window.
– or –
Click on the "Load" button (under "Report").
The "Load Report" window opens.
Fig. O-25
2. Under "Directories:", select the location where the report has been stored.
3. In the "File Name:" text box, enter the name of the report that you want to view (file name
extension *.htm).
4. Click on the "Load" button.
The report with the name you entered will be displayed.
2.5.4

Printing the report

To print out a report, proceed as follows:
A printer is connected to socket [5] PRINTER of the ANT-20 and an appropriate printer driver
is installed.
The report that you want to print out is displayed in the HTML viewer.
1. Click on the "Print Preview" item in the "File" menu in the HTML viewer.
Once the report has been formatted, the "Preview Form" window opens.
2. Click on the "Print ..." button.
The currently-loaded page of the report will be printed out.
2.5.5

Adding a logo to the report

The company logo for Wavetek Wandel Goltermann is shown in the top right hand corner of the
report. You can replace this logo with your own company logo:
• Format: GIF
• Size: < 256 x 150 pixels
• File name: LOGO.GIF
1. Generate a file (LOGO.GIF) containing your company logo.
2. Save the file in the "C:\ANT_NEXT" directory.
The existing logo will be overwritten.
O-20
"Load Report" window
ANT-20SE
Operating
