ANT-20SE

Operating

"Operating" is divided into two sections:
• Section 1 "For users in a hurry" describes how you can use the "ANT-20 NEXT" software to
perform a pre-defined measurement application.
• Section 2 "For advanced users" describes the software functions in detail. This section is
aimed at users who want to customize, edit or expand the "ANT-20 NEXT" software to meet
their specific requirements.
1

For users in a hurry

1.1

Connecting the items under test

⇒ Connect the items under test according to the line type to the following sockets on the
ANT-20:
Socket
[12]
[13]
[14]
[15]
[16]
[17]
[18]
Table O-1
Operating
Description
Electrical input (balanced)
Electrical output (balanced)
Electrical input (encoded)
1.5 to 156 Mbit/s
Electrical output (encoded)
1.5 to 156 Mbit/s
Electrical input STM-1/STM-4
622 Mbit/s
Optical input OC-1/-3/-12/STM-1/STM-4
1310/1550 nm
Optical output OC-1/-3/-12/STM-1/STM-4
1310/1550 nm
Connecting sockets on the ANT-20
ANT-20 NEXT
O-1
