ANT-20 NEXT
Test
Intrinsic jitter HP2 (18 kHz/100 kHz):
< 0.2 UI
MTJ
M.2100/G.826
Table SA-5
Alarms and error messages
If alarms occur or limit values are exceeded, a brief explanatory text is displayed in the "Possible
Causes" field of the "ANT-20 NEXT - [Application]" window. A more detailed cause description
and further information can be displayed if you double-click on the item of interest and the
necessary information is stored in the "knowledge database". You can add to or edit the texts
stored in the "knowledge database".
Also refer to Section 2.6.2 "Customizing an application", Page O-22 for more information.
Adaptations
You can adapt the "Line 2 Mb/s, transparent (unframed), no re-timing, full test (approx. 25 min)"
application to suit your special requirements. This applies in particular to the jitter and G.826
tests and also to the "re-timing" property that is either expected or to be eliminated. You can also
change the limit values and gate times.
Also refer to Section 2.6 "Creating and customizing applications", Page O-21 for more
information.
SA-12
pp
Measurements performed (continued)
Explanation
Intrinsic jitter measured with HP2 (18 kHz high-pass filter)
The requirements of ITU-T G.823 must be met.
No errors may occur for measurement times of up to 24 hours.
Test signal: PRBS15
A G.826 "Out of Service" analysis is performed.
ANT-20SE
Standard Applications
