Appendix D: PFT Packing to Ship for Repair and Service

Note: All items must be packed as shown. If your packaging is missing, please
contact Brookfield Engineering for replacement parts. Failure to do so
could result in costly damage to the PFT.
If you saved the original packing instructions which came with the PFT, use them in
accordance with the following instructions on page 63.
If you have ordered new packaging materials from Brookfield or an authorized dealer
(Part Number: PFT-REPACK), the following items have been provided in the Repack Kit:
PFT RSC 500DW (accessory box) (qty 1):
PFT HSC 500DW (large outer box) (qty 1):
PFT Tray Stitched (qty 1):
1.7# PE Foam D/C's (bottom) (qty 1):
1.7# PE Foam D/C's (top) (qty 1):
PFT Shipping Pallet (qty 1):
Poly Bag for PFT Shipping Pack (qty 1):
Shipping Foam, Compression Plate (qty 1):
Shipping Foam (6-inch Trough) (qty 1):
Shipping Foam (5-inch Trough) (qty 1):
3x3x3 .225 Strapping Protectors (qty 8):
Label, Box, Packaging & Shipping Info (qty 2):
Set of 2, 1in. x 12ft. Lashing Straps (qty 2):
PFT Packing Instructions for Shipping (qty 1):
Velcro Strapping, 5/8 wide (qty 1):
Bubble bags, rubber bands and packing newspaper will also be supplied in the Repack Kit.
Detailed instructions for packaging the PFT proceed on the following page. It is important
to follow these instructions completely in order to prevent damage to the PFT during
shipment.
AMETEK Brookfield Page 66
PFT-PACK1
PFT-PACK2
PFT-PACK3
PFT-PACK4
PFT-PACK5
PFT-PALLET
PFT-BAG
PFT-104
PFT-101
PFT-106
CTN-14
LBL11-PFT3
PFT-116
T11-1041
PFT-115
Manual No. M09-1200-F1016
