4.4. Soot...Oil trace

Under „Soot...Oil trace" the measurement results for boiler temper-
ature, soot number and oil derivative can be entered. Select the cor-
responding line in the display and activate the entry by <Enter>. The
input for boiler temperature and soot number (3 measurements) can
be done as follows:
-select with the keys <store> (left) and <Print> (right) the position
which should be changed (corresponding field is blinking)
-enter the designated number with the curser keys <up/down>
By pressing the key <Enter> the entry will be transferred to the data
record of the measurement. The result of the oil derivative checking
will be documented as follows:
-set cursor to line „Soot...Oil trace"
-select the result with the key <Enter>
("No", "Yes" or "- - - ")
When all necessary entries have been made the entry can be closed
by pressing the key <ESC>. The measurement is now completed.
4.5. Record and print Measurement
After the gas analysis, please transfer the recorded
data (intermediate memory) into the internal
instrument memory otherwise the values will
After scrolling back to the gas measure-
ment with the cursor keys <up/down> the
measurement can be transferred to the
internal memory with <Enter> / <Store to
memory> / Enter> (after successful stor-
age an "M" will appear right down in the
display). Finally a print-out (IR printer re-
quired) of the results can be made (key
<Print>).
Page 12
get lost by instrument switch-off!
Soot...Oil trace
T.Boiler
1.Soot meas.
2.Soot meas.
3.Soot meas.
Oil trace
↵ ↵ ↵ ↵
Input:
Display/Memory
Memory
Store to memory
Display values
CO MV ON/OFF
↵ ↵ ↵ ↵
Continue with:
↑↓
ecom-B
--- °C
---
---
---
---
