Picture 135: Measured Time; Picture 136: Packet Statistics Values - Image Access WideTEK 48 Setup Manual

The result of the measurement is displayed at the next screen.
The bar graphic shows the three values:
Minimum The fastest transfer time between the scanner and the target address.
Average The average time for all transferred packets.
Maximum The maximum transfer time during the test.
Depending at the transfer time, the color of the bar changes.
E.6.4.1.2 Packet Statistics
Packet Statistics
Page 144

Picture 135: Measured Time

Shows the current network packet statistics.

Picture 136: Packet Statistics values

/
