General Specifications

8 General Specifications

8.1 Electrical Data

8.1.1 Power Rating

Grid conditions:
Supply voltage
Mains voltage low / mains drop-out:
During low mains voltage or a mains drop-out, the Filter continues until the intermediate circuit voltage drops below the
minimum stop level, which corresponds typically to 15% below the filter lowest rated supply voltage. Full compensation cannot
be expected at mains voltage lower than 10% below the filter lowest rated supply voltage. If mains voltage exceed the filter
highest rated voltage the filter continues to work but harmonic mitigation performance is reduced. Filter will not cut out until
main voltages exceed 580V.
Supply frequency
Max. imbalance temporary between mains phases
where mitigation performance is kept high.
Max THDv pre-distortion
Harmonic Mitigation Performance:
THiD
Individual harmonic mitigation ability:
5th
7th
11th
13th
17th
19th
23rd
25th
Total current of harmonics
Reactive Current Compensation:
Cos phi
Reactive current, % of filter current rating
Cable lengths and cross sections:
Max grid cable length
Maximum cross section to control terminals, rigid wire
Maximum cross section to control terminals, flexible cable
Maximum cross section to control terminals, cable with enclosed core
Minimum cross section to control terminals
CT terminals specification:
Needed CT number
AAF's burden equals
Secondary current rating
Accuracy
VLT Active Filter AAF 00x
Filter will mitigate at higher mains imbalance but harmonic mitigation
MG.90.V2.02 - VLT® is a registered Danfoss trademark
3.0% of rated supply voltage
10% with kept mitigation performance
Reduced performance for higher pre-distortion levels
Depending on filter vs. distortion ratio.
% of filter current rating
Controllable 1.0 to 0.5 lagging
Unlimited (determined by voltage drop)
1.5mm 2
1A or 5A (hardware setup)
380-480V
50/60Hz ±5%
performance is reduced
Best performance <4%
70%
50%
32%
28%
20%
18%
16%
14%
90%
100%
/16 AWG (2 x 0.75 mm 2
2
1mm /18 AWG
2
0.5mm /20 AWG
2
0.25mm
3 (one for each phase)
2mΩ
Class 0.5 or better
