How to Programme

6.11 Parameter Lists

6.11.1 Default settings

Changes during operation:
"TRUE" means that the parameter can be changed while the Active Filter is in operation and "FALSE" means that the unit
must be stopped before a change can be made.
4-Set-up:
'All set-up': the parameter can be set individually in each of the four set-ups, i. e. one single parameter can have four
different data values.
'1 set-up': data value will be the same in all set-ups.
SR:
6 6 Size related
Conversion index:
This number refers to a conversion figure used when writing or reading by means of an active filter.
Conv. 100
index
Conv. 1
factor
Data type
2
3
4
5
6
7
9
33
35
54
76
75 74 70 67 6
3600000 3600 60 1/60 100000
0
Description
Integer 8
Integer 16
Integer 32
Unsigned 8
Unsigned 16
Unsigned 32
Visible String
Normalized value 2 bytes
Bit sequence of 16 boolean variables
Time difference w/o date
MG.90.V2.02 - VLT® is a registered Danfoss trademark
VLT Active Filter AAF 00x
N/A:
No default value available.
5 4 3 2
10000 10000 1000 100
0
1 0 -1 -2 -3
10 1 0.1 0.01 0.001 0.000
-4 -5 -6
0.00001 0.00000
1 1
Type
Int8
Int16
Int32
Uint8
Uint16
Uint32
VisStr
N2
V2
TimD
