SAN Volume Controller connectors

The external connectors for the SAN Volume Controller can be located easily.
1
8 7
Use the reference keys below to cross reference the reference keys in the example
above:
The following figure shows the type of connector located on the power supply
assembly. The connector allows you to connect the SAN Volume Controller to the
power source from the uninterruptible power supply.
7
Service controller card
8
Fan assembly (4)
9
Air baffle
10
Microprocessor heat sink retention module
11
System board
12
DIMM modules (4)
13
Microprocessor Voltage Regulator
14
Microprocessor
15
Microprocessor heat sink
16
Fibre-channel adapters (2)
2 3
6
1
Power connector indicator
2
Fibre-channel port 3
3
Fibre-channel port 4
4
Ethernet port 2 (not used on the SAN Volume Controller)
5
Ethernet port 1
6
Serial connector
7
Fibre-channel port 2
8
Fibre-channel port 1
4
5
Chapter 1. Overview of the SAN Volume Controller
11
