Hardware for the uninterruptible power supply 5125
26
IBM TotalStorage SAN Volume Controller: Installation Guide
Diagrams of the hardware for the uninterruptible power supply (UPS) 5125 are
shown below:
Locations for the uninterruptible power supply 5125 connectors and circuit
breakers
1
1
Signal cable connectors
2
Main power connector
3
Output connectors
4
Circuit breakers
Neutral
Ground
Live
2
3
4
