Hardware for the uninterruptible power supply 5115
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
When the general alarm indicator is accompanied by the audio alarm beeping every
5 seconds, the battery is low. If the audio alarm is continuous, the internal
temperature of the UPS 5125 is too high, or there has been a momentary output
overload.
Diagrams of the hardware for the uninterruptible power supply (UPS) 5115 are
shown below:
Locations for the uninterruptible power supply 5115 connectors
1
Main power connectors
2
Communication port
3
Load segment 1 receptacles
4
Load segment 2 receptacles
Hardware locations for the uninterruptible power supply 5115
3
4
1
Frame assembly
2
Battery pack assembly
3
Battery plate
4
Front panel assembly
Uninterruptible power supply power connector
1
2
1
2
Chapter 2. Overview of the uninterruptible power supply
3
4
25
