Optex SMDC-16 Programming Manual page 8

1. System Times 1. System Times
1 . 2 C u t o f f T i m e s (continued) 1 . 2 C u t o f f T i m e s
1.2.3 Relay 1 Cutoff
RELAY 1 CUTOFF
10 MINUTES
Select the amount of time in minutes Relay 1 will remain energized.
1.2.4 Relay 2 Cutoff
RELAY 2 CUTOFF
10 MINUTES
Select the amount of time in minutes Relay 2 will remain energized.
1.2.5 PGM 1 Cutoff
PGM 1 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 1 will remain energized.
1.2.6 PGM 2 Cutoff
PGM 2 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 2 will remain energized.
1.2.7 PGM 3 Cutoff
PGM 3 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 3 will remain energized.
1.2.8 Listen-In Cutoff
LISTEN IN CUTOFF
00 MINUTES
Select the amount of time in minutes Listen-In will remain energized.
(additional equip. required).
1 . 3 S e l f T e s t 1 . 3 S e l f T e s t
Self Test reports can be used to periodically test the integrity of the communication link
between the SMDC and the central station. Test reports may be sent on a daily
or weekly basis.
1.3.1 Daily Self Test
DAILY TEST RPT
NO 0=NO 1=YES
Enable this option for the SMDC to transmit a self test report on a daily basis.
(see 1.3.4-Test Rpt Code / 1.3.5-Ab Test Rpt Code / 3.8.3-Rcvr Routing)
1.3.2 Weekly Self Test
WEEKLY TEST RPT
NO 0=NO 1=YES
Enable this option for the SMDC to transmit a self test report on a weekly basis.
1.3.2 Day of Week
DAY OF WEEK
NO 0=NO 1=YES
Select the day of the week for transmission of the self test code after weekly test has been enabled.
(see 1.3.4-Test Rpt Code / 1.3.5-Ab Test Rpt Code / 3.8.3-Rcvr Routing).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: 0-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes
Default: 10 minutes
Selections: 00-99 minutes
Default: 10 minutes
Selections: 00-99 minutes
Default: 00 minutes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
0 Selections: 1-7
Default: 0
SMDC-16 Program Manual
1. System Times
1. Delay Times
1. Pre-Alarm
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
2. Cutoff Times
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
8. Listen - In
3. Self Test
1. Daily
2. Weekly
3. Time of Day
4. Self Test Code
5. Abnormal test Code
6. Telco Test Report
7. Radio Test Report
4. Real Time Clock
1. Time Clock
1. Set Date
2. Set Time
2. Set by User
3440-0252 A4
