Optex SMDC-16 Programming Manual page 17

2. Zone Configuration 2. Zone Configuration
2 . 2 . 3 Z o n e O u t p u t s 2 . 2 . 3 Z o n e O u t p u t s
2.2.3.5 Relay 1
TY# RELAY 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate Relay 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.6 Relay 2
TY# RELAY 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate Relay 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.7 PGM 1
TY# PGM1
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.8 PGM 2
TY# PGM 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.9 PGM 3
TY# PGM 3
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 3 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2 . 3 C r o s s Z o n e P a i r s 2 . 3 C r o s s Z o n e P a i r s
The use of Cross Zones Pairs will help in the reduction of false alarms in that the SMDC
must recognize the activation of two zones within a programmable time period before an
actual alarm condition will be generated by the SMDC. The SMDC allows for a
maximum of sets of Cross Zone pairs that both share a common time. Typic al applications
may be two sets of outdoor photoelectric beams or two interior detectors.
2.3.1 Cross Zone Pair 1
2.3.1.1 Zone A
PAIR 1 / ZONE A
Zone 00
Select the applicable zone that will be used for Zone A of Cross Zone Pair 1.
2.3.1.2 Zone B
PAIR 1 / ZONE B
Zone 00
Select the applicable zone that will be used for Zone B of Cross Zone Pair 1.
2.3. 2 Cross Zone Pair 2
2.3.2.1 Zone A
PAIR 2 / ZONE A
Zone 00
Select the applicable zone that will be used for Zone A of Cross Zone Pair 2.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 1-80
Default: 00
Selections: 1-80
Default: 00
Selections: 1-80
Default: 00
SMDC-16 Program Manual
2. Zone Configuration
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
6. # of Expander Bds.
