5. Report Codes

5 . 3 R e p o r t C o d e M e n u 3 ( c o n t i n u e d )

5.3.4 Aux. Power Fail

AUX. POWER FAIL

code: NO

Select the Aux. Power Fail report code that will be transmitted to central station when the

SMDC failure of Aux. power. (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on

page 42 & 43).

5.3.5 Aux. Power Restore

AUX. POWER REST

code: NO

Select the Aux. Power Restore report code that will be transmitted to central station when the

Auxiliary Power is restored (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on

page 42 & 43).

5.3.6 Ground Fault Code

GND FAULT CODE

code: NO

Select the Ground Fault Code report that will be transmitted to central station when a ground

is detected on any of the zone inputs or if the ground is removed from the SMDC.

(see wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).

5.3.7 Force Arm Code

FORCE ARM CODE

code: NO

Select the Force Arm Code report code that will be transmitted to central station when a

PIN has been used to force arm/disarm the control panel.

(see 3.8.3-Rcvr Routing / 4.7-Force Arm Enabled / SIA-Contact ID-Hex chart on page 42 & 43 /

User Manual).

5.3.8 On Premise Report Code

ON PREM CODE

code NO

Select the On Premise Report Code report code that will be transmitted to central station

when the SMDC has been armed in the Stay or Instant mode.

(see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43 / User Manual).
