Optex SMDC-16 Programming Manual page 15

2. Zone Configuration 2. Zone Configuration
2 . 2 . Z o n e T e m p l a t e s ( P r e - D e f i n e d = Y e s ) 2 . 2 . Z o n e T e m p l a t e s ( P r e - D e f i n e d = Y e s )
There are nine Zone Templates available which corresponds to the individual zone types
(1 - 9). Select the Zone Type upon entering this menu that you wish to program.
2.2.1 Loop Response
TY-# LP RESP
0005x50ms
Enter the amount of time necessary for the SMDC to react to an abnormal condition.
2.2.2 Zone Features
This section determines the individual characteristics each zone will have.
2.2.2.1 Silent Day / Audible Night
TY# SILENT DAY
NO 0=NO 1=YES
The SMDC will not energized either bell 1 or bell 2 outputs when the alarm system
is in a disarmed condition if enabled. However the PGMs and the relay outputs will change
state if programmed as an alarm output. The SMDC will activate the bell outputs when
this zone is activated during an armed period.
Note: This option is to be used with 24 hour, Fire and Day zones only.
2.2.2.2 Telephone
TY# TELEPHONE
YES 0=NO 1=YES
Enable this option to allow all zones report codes to transmit via telephone to the central
station.
(see 2.1.3 Report Codes)
2.2.2.3 Radio
TY# RADIO
NO 0=NO 1=YES
Enable this option to allow all zone report codes to transmit via Varitech long range radio
to the central station.
(See 2.1.3-Report Codes / 3.9-Radio Options).
2.2.2.4 Bypass Allowed
TY# BYPASS
YES 0=NO 1=YES
This option determines if this zone will be able to be bypassed by the user.
(see user manual for PIN authorization levels).
2.2.2.5 Shunt Allowed
TY# SHUNT
YES 0=NO 1=YES
This option determines if this zone will automatically cease sending alarm report codes to
the central station after the programmed number of activation's (2.4-# Shunt Alarms) and
time period (2.5-Shunt Period).
W a r n i n g : The alarm outputs will continue to activate on each new alarm condition. W a r n i n g
2.2.2.6 Display Armed
TY# DSP ARMED
YES 0=NO 1=YES
This option determines if this zone description will be displayed on the keypad once the
SMDC senses an alarm activation during the armed period.
N o t e : The zone description will not display if Group Arming is enabled. N o t e
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: 0001-9999 x 50 ms
Default: 0005x50 ms
Selections: 0001-9999
Default: 0001x50 ms
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
SMDC-16 Program Manual
2. Zone Configuration
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
6. # of Expander Bds.
3440-0252 A4
