Optex SMDC-16 Programming Manual page 18

2. Zone Configuration 2. Zone Configuration
2 . 3 C r o s s Z o n e P a i r s 2 . 3 C r o s s Z o n e P a i r s
(continued)
2.3.2.2 Zone B
PAIR 2 / ZONE B
Zone 00
Select the applicable zone that will be used for Zone B of Cross Zone Pair 2.
2.3.3 Cross Zone Timer
CROSS ZONE TIME
00 seconds
Select the time "window " for both Cross Zone Pairings the SMDC must wait before
before creating an actual alarm condition.
2 . 4 N u m b e r o f S h u n t A l a r m s 2 . 4 N u m b e r o f S h u n t A l a r m s
# OF SHUNT ALM
00
Select the number of alarms that must occur before the SMDC will auto bypass the zone.
(see Shunt Allowed 2.1.7.5 / Shunt Period).
2 . 5 S h u n t P e r i o d 2 . 5 S h u n t P e r i o d
SHUNT PERIOD
00x10 MINUTES
Select the time period that will allow the SMDC to auto bypass this zone.
(see 2.1.7.5 Shunt Allowed / Number of Shunt Alarms).
2 . 6 N u m b e r o f E x p a n d e r B o a r d s 2 . 6 N u m b e r o f E x p a n d e r B o a r d s
# of EXP BDS
00
Select the total number of expander boards that will be installed.
N o t e : The SMDC will not allow you to program or scan past the main sixteen zones N o t e :
if the correct number of expander boards has not been enabled.
2 . 7 W i r e l e s s O p t i o n s 2 . 7 W i r e l e s s O p t i o n s
N o t e : The SMDC will not allow arming if there has been a low battery trouble or a "fail to N o t e :
check in" trouble (not respoding).
The SMDC-WX (wireless features) have not been investigated for use in
UL Listed Fire Applications or UL Listed Burglar Applications
2.7.1 System ID
SYSTEM ID
NO
Enter the unique operating code for the wireless receiver.
N o t e : This option will allow you to set a SMDC so that it will not receive interference N o t e :
from a neighboring SMDC wireless system.
(additional equipment required).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: 1-80
Default: 00
Selections: 00-255 seconds
Default: 00 seconds
Selections: 00-99
Default: 00
Selections: 00x10 minutes
Default: 00 minutes
Selections: 0-8
Default: 0
Selections: 00 - 99
Default: No
SMDC-16 Program Manual
2. Zone Configuration
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
6. # of Expander Bds.
3440-0252 A4
