7. C.S. Downloading 7. C.S. Downloading
This section determines the parameters necessary for off/on-site programming using the
SRPU (Super Remote Programming Utility) software. Contact Tech Support at
Optex Inc. to obtain a copy of the SRPU software.
7 . 1 P h o n e N u m b e r 7 . 1 P h o n e N u m b e r
PHONE NUMBER
(BLANK)
Enter the telephone number the SMDC will need dial in order to connect with
the computer modem that has the SRPU software loaded on it.
N o t e : To delete this telephone number press RESET. N o t e :
Dialer Chart
Selections:
Instant Key
Memory Key
Stay Key
Away Key
7 . 2 N u m b e r o f R i n g s 7 . 2 N u m b e r o f R i n g s
NUMBER OF RINGS
08
Enter the number of rings the SMDC will wait before automatically answering
the call placed by the computer with the SRPU software. If at the subscriber site another
device is connected to the same phone line (i.e.: an answering machine) that answers the call
prior to the ring count being reached, the SMDC will still listen for the lead in tone from the
SRPU software, and if the control panel recognizes the proper frequency, it will seize the
phone line from the devices that initially answered the call and begin communication. The
SMDC is able to communicate with the SRPU on either phone line connected to the panel
at the subscriber's premise.
7 . 3 C a l l e r I D E n a b l e 7 . 3 C a l l e r I D E n a b l e
CALLER ID
NO O=NO 1=YES
Enable this option should the phone line connected to the SMDC have Caller ID service.
N o t e : Caller ID service can in some instances can cause interfere with the operation of the N o t e :
panel if the option is not enabled.
7 . 4 L o c a l D o w n l o a d P I N 7 . 4 L o c a l D o w n l o a d P I N
LOCAL PIN
(BLANK)
Enable this option to allow for the Local Download PIN to initiate a remote programming
session from the keypad.
N o t e : By entering this PIN number and then pressing the PROGRAM key enables the panel N o t e :
to dial the phone number programmed in 7.1. To delete this number press RESET.
7 . 5 P a n e l A c c e s s I D 7 . 5 P a n e l A c c e s s I D
PANEL ACCESS #
0000
Enable this option to allow the SRPU software to connect with the SMDC to determine if the
SMDC Access ID matches the SRPU Access ID. Programming is allowed once a match is
confirmed. The session will be terminated immediately if a match is not confirmed.
N o t e : FFFF (monitor 4 times) will delete the Access ID number and download access will be denied. N o t e
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual
Selections: Up to 16 characters
Default: Blank
= 0 through 9
= 3 second dial pause (appears as a ":")
= 5 second dial tone detect (appears as a ";")
= # (pound)
= * (asterisk)
Selections: 0 - 15
Default: 08 (0 = disabled)
Selections: Yes / No
Default: No
Selections: Blank, 0000 - 9999
Default: Blank
Selections: 0000 - 9999
Default: 0000
48 of 59
7. Downloader
1. Phone Number
2. Number of Rings
3. Caller ID Enable
4. Local Download PIN
5. Panel Access ID
