Optex SMDC-16 Programming Manual page 32

4. System Options 4. System Options
4 . 3 . S y s t e m F e a t u r e s 4 . 3 . S y s t e m F e a t u r e s
(continued)
4.3.2 O/C View by User
OP/CL VIEW USER
YES 0=NO 1=YES
Enable this option to allow the users to view all opening and closing historical events that
have occurred. (see 0 Pager/Fax/Printer / users manual).
4.3.3 Silent Trouble
SILENT TRBL
NO 0=NO 1=YES
Enable this option for all SMPCs to be silent if a trouble condition occurs between the
hours of 9:00pm to 7:00am. Note: Not for Fire Alarm System Installations.
4.3.4 Not Used / Reserved for Future Use
Not Used / Reserved for
Future Use
4.3.5 50Hz / 60Hz
50 HZ
NO 0=NO 1=YES
Enable this option to allow the SMDC to operate on 60Hz or 50Hz
(see 1.4-Time Clock)
4.3.6 AC/Crystal Clock
CRYSTAL CLOCK
NO 0=NO 1=YES
Enable this option to allow the clock to operate on a crystal or AC cycles.
(see 1.4 Time Clock Options).
N o t e : AC cycles will allow for a accurate clock operation. N o t e :
4.3.7 Power Delay Time before Zone Processing
POWER UP DELAY
10 seconds
Enable this option to allow the SMDC to ignore the zone's status upon the return
of AC and DC power.
N o t e : This option is especially helpful when motion detectors or other powered devices N o t e :
connected to the SMDC need a period of time to stabilize after power has restored to
the SMDC.
4.3.8 PIN Entry Required for Zone Scan
PIN FOR SCAN
YES 0=NO 1=YES
Enable this option to require an authorized user PIN to perform a zone scan.
(see User Manual for levels).
4.3.9. Threshold of Bad Codes
# OF BAD CODES
00
Enable this option to allow the SMDC to send an Unauthorized User report code to the
central station after the programmed number of consecutive unauthorized attempts to secure
a PIN has been entered at a keypad
(see 5.3.3 Unauthorized User report code).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: 50Hz / 60Hz
Default: 60Hz
Selections: AC / Crystal
Default: AC
Selections: Blank, 01-99 seconds
Default: 10 seconds
Selections: Yes / No
Default: Yes
Selections: Blank, 1-99
Default: 00
SMDC-16 Program Manual
32 of 59
4. System Options
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
4. INP-1 Function
3440-0252 A4
