5. Report Codes

5 . 1 . R e p o r t C o d e M e n u 1 ( c o n t i n u e d )

5.1.8 Bell Trouble Restore

BELL TRBL REST

code: NO

Select the Bell Trouble Restore report code that will be transmitted to the central station

when the SMDC detects a restore condition on Bell 1's circuit. (see Wiring diagram /

3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).

5.1.9 Duress

DURESS RPT CODE

code: NO

Select the Duress report code that will be transmitted to the central station when the Duress

PIN number is entered at any of the keypads. (see 3.8.3-Rcvr Routing / 6.2-PIN Numbers /

SIA-Contact ID-Hex chart on page 42 & 43).

5 . 2 . R e p o r t C o d e M e n u 2

Program the appropriate report codes for the following options.

5.2.1 Bus Fault

BUS FAULT

code: NO

Select the Bus Fault report code that will be transmitted to the central station when the

control panel has sensed a trouble condition on either the Omnet Bus (used for expansion

modules) or the Keypad Bus. (see Wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex

chart on page 42 & 43).

5.2.2 Bus Restore

BUS RESTORE

code: NO

Select the Bus Restore report code that will be transmitted when the Omnet or Keypad

bus restores to a normal condition. (see Wiring diagram / 3.8.3-Rcvr Routing /

SIA-Contact ID-Hex chart on page 42 & 43).

5.2.3 Bell Restore

BELL RESTORE

code: NO

Select the Bell Restore report code that will be transmitted to the central station when after the

bell circuit has reset and the circuit that initiated the activation has been restored to a normal

condition. This code is common for both bell outputs. (see Wiring diagram / 3.8.3-Rcvr Routing /

SIA-Contact ID-Hex chart on page 42 & 43).

5.2.4 Open Restore

OPEN RESTORE

code: NO

Select the Open Restore report code that will be transmitted to the central station when the control

panel has been disarmed after an alarm condition.

N o t e : The circuit that caused the alarm condition must be in a secure condition before this report

N o t e :

will be transmitted.

(see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).

5.2.5 Exit Error

EXIT ERROR

code: NO

Select the Exit Error code that will be transmitted to the central station when an Entry/Exit

zone has been left open after the exit time has expired.

(see 1.2 Exit Delay Time / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).

Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual
