8. Schedules 8. Schedules
8 . 2 W i n d o w S y s t e m (continued) 8 . 2 W i n d o w S y s t e m
8.2.5 Temporary Schedule 2 (continued)
8.2.5.1.3 Close Start Time
1 CLOSE START
__:__ AM 1=PM
Select the Close Start time for Temporary Schedule 2.
After you have completed the programming for Temporary Schedule 2-Group/Partition 1,
proceed to program the remaining Temporary Schedule 2 for Groups/Partitions 2-8 as needed.
8 . 3 A u t o A r m 8 . 3 A u t o A r m
Auto arm will allow for the SMDC to arm itself automatically should the user
inadvertently vacate the premises without entering his or hers PIN. All zones must be in a
secure condition for the panel to successfully perform an auto arm.
N o t e : The Auto Arm feature follows the prescribed times set forth in schedule one only for a N o t e :
Group or Non-Group system.
N o t e : The Auto Arm feature follows the prescribed times set forth in schedules 1-8 only for a N o t e :
Keypad Partitioned system.
(see 8.1.1-Schedule 1 Enabled / 8.2.1-Schedule System).
8.3.1 Auto Arm On
AUTO ARM ON
NO 0=NO 1=YES
Enable this option for the Auto Arm function to operate.
N o t e : Auto arm will not perform if zone(s) are not secure. N o t e :
8.3.2 Auto Arm Code
AUTO ARM CODE
code NO
Select the Auto Arm report code that will be transmitted to the central station if the
SMDC has successfully performed an auto arm.
(see 8.3.3-Auto Arm Fail Code / SIA-Contact ID-Hex chart on page 42 & 43).
8.3.3 Auto Arm Fail Code
AUTO FAIL CODE
code NO
Select the Auto Arm Fail report code that will be transmitted to the central station if the
SMDC has not successfully performed an auto arm.
(see 8.3.2-Auto Arm Code / SIA-Contact ID-Hex chart on page 42 & 43).
8.3.4 Pre Close Warning
PRE-CLOSE WARNING
NO 0=NO 1=YES
Enable this option to allow the SMPCs to emit a tone 10 minutes prior to the end of
the close window for Schedule 1 only.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual
Selections
Default: No Time
Selections: Yes / No
Default: No
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: Yes / No
Default: No
54 of 59
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
