- Page 1 S M D C - 1 6 S M D C - 1 6 USER’S MANUAL SMDC-16 Digital Control Communicator SMPC-32 Personal Control...
-
Page 2: Table Of Contents
Holiday Schedules - Tomorrow & Next Monday C harts PIN Authorization Levels UL Smoke Detector Sensor Information 14 - 15 Sensor / Keypad Location Chart Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 2 of 16... -
Page 3: Description Of Your Alarm System
SMDC and the arming pads will be called the SMPC. The SMDC is an ongoing project in advance technology from Optex Inc. which incorporates many new and innovative features to ensure that the system is easily operated by yourself and all other authorized users of the system. Please take a few moments to review this manual and familiarize yourself with your new security system and the benefits and peace of mind that it is intended to furnish. - Page 4 Keypad will display “Enter Command”. Œ•Ž• + CLEAR Example: Œ•Ž• Warning tone - press + CLEAR. (continued on next page) (continued) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 4 of 16...
-
Page 5: Force Arming
• There are two methods of Instant Disarming: (continued) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 5 of 16... -
Page 6: Arming / Disarming Your Alarm System (With Groups)
(G ### represent group numbers). system armed. • There are two methods of Stay Group Arming: Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 6 of 16... - Page 7 Press CLEAR to disarm all groups. Enter your PIN. Keypad will display “DISARM ?” Press CLEAR to disarm all groups. (continued) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 7 of 16...
-
Page 8: About Your Alarm System
* Note : Memory moves you in reverse. system had been armed in either of the three arming modes AWAY, STAY or INSTANT. (continued) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 8 of 16... -
Page 9: Scanning Zones
Done” and “Clear to Exit. By pressing the CLEAR button the system will revert to the normal operating Continued mode. (Continued on next page) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 9 of 16... -
Page 10: Sensor Reset Operation
This will assist your installing company in determining if there was a problem on your fire circuit and which detector might have created the problem. Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3... -
Page 11: Programming Pins
Enter the time and then press 0 for AM or 1 for • Date The keypad display will be requesting that you enter the date. (continued) (continued on next page) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 11 of 16... -
Page 12: Schedule
11. _ _ : _ _ AM 0 = am - 1 = pm (your entry will pulsate). 12. Press ENTER and then CLEAR. (continued on next page) (continued) Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 12 of 16... -
Page 13: Extend Close Time
Level 5 PIN Change Clock Settings Change Schedules Enter/Exit Monitor Mode Enter/Exit Walk Test Mode Extend Closing Time View History Buffers Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 13 of 16... -
Page 14: Ul Smoke Detector Sensor Information
The detector should be positioned relative to the stairway so as to intercept smoke coming from a fire in the basement before the smoke enters the stairway. Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual... - Page 15 Measurements shown are to the Side closest edge of the detector. wall Figure A-3.2.1 Example of proper mounting for detectors. Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 15 of 16...
- Page 16 User’s M a n u a l Zone Zone Name Location Zone Zone Name Location Number Number Keypad Location Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 User’s Manual 3440-0250 A3 16 of 16...
